Chieftec VEGA PPG-750-S 750W 80+ Gold ATX 3.1 Non-Modular (Boxed)
750W ATX 3.1 PSU with 80 PLUS Gold efficiency, non-modular cables, 135mm FDB fan. PCIe Gen5 ready (1x12+4-pin, 4x6+2-pin). LLC topology for stability. Ideal for gaming PCs.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 800 - 899 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Non-modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12V-2x6 4x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
The Chieftec VEGA Series PPG-750-S is a 750W power supply compliant with Intel ATX 12V 3.1 and PCIe Gen5 standards, featuring 80 PLUS Gold certification for up to 92% efficiency. It uses an LLC Half-Bridge converter with DC-to-DC technology for stable power delivery and reduced losses.
Equipped with extra-long non-modular black cables, a 135mm FDB silent fan for optimal cooling and low noise, and comprehensive protections (OVP, UVP, OCP, SCP, OTP). Includes 1x 12+4-pin PCIe (600mm), 4x 6+2-pin PCIe, 1x 4+4-pin EPS, 6x SATA, 3x Molex connectors.
- ATX 3.1 & PCIe Gen5 compliant
- 80 PLUS Gold efficiency
- 135mm FDB fan
- Non-modular design
- Dimensions: 150x150x86mm
- Weight: 1.96kg (packaged 2.46kg)
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 60 cm |
| Number of SATA power connectors | 6 |
| SATA power cable length | 400 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 400 mm |
| EPS power connector (8-pin) | Yes |
| EPS power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (12+4 pin) | 1 |
| PCI Express power connectors (12+4 pin) cable length | 600 mm |
| PCI Express power cable length | 60 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 65 cm |
| ATX Power connector (24-pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Cabling type | Non-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | FDB |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Illumination | No |
| Certification | 80PLUS Gold |
| Weight | 1.96 kg |
| Package weight | 2.46 kg |
| Dimensions (LxWxH) | 150 x 150 x 86 mm |
