ZOTAC GeForce RTX 5060 Twin Edge OC - 8GB GDDR7, Boost 2527 MHz, Dual-Fan, PCIe 5.0
Compact ZOTAC GeForce RTX 5060 Twin Edge OC — 8GB GDDR7, 2527 MHz boost, DLSS4/Blackwell, 3x DP2.1b, 1x HDMI2.1b, PCIe 5.0, VR ready.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| GPU (Graphics Cards) - VRAM Capacity | 8 GB |
|---|---|
| GPU (Graphics Cards) - Cooler Type | Open-air (axial) |
The ZOTAC GAMING GeForce RTX 5060 Twin Edge OC is a compact graphics card powered by NVIDIA‘s cutting edge Blackwell Architecture, DLSS4 and 8GB of GDDR7 memory. With a factory OC as well as a solid cooling solution, the Twin Edge OC is ready to take on the latest title releases with smooth framerates and performance.
| CUDA | Yes |
| CUDA cores | 3840 |
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 5060 |
| Processor boost clock speed | 2527 MHz |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| Discrete graphics card memory | 8 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 128 bit |
| Data transfer rate | 28 Gbit/s |
| Interface type | PCI Express x8 5.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| DisplayPort version | 2.1b |
| TV tuner integrated | No |
| DirectX version | 12 Ultimate |
| OpenGL version | 4.6 |
| Virtual Reality (VR) ready | Yes |
| HDCP | Yes |
| HDCP version | 2.3 |
| Dual Link DVI | No |
| NVIDIA G-SYNC | Yes |
| Overclocked (OC) edition | Yes |
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Fan diameter | 9 cm |
| Number of slots | 2 |
| SFF ready | Yes |
| Product colour | Black |
| Minimum system power supply | 550 W |
| Supplementary power connectors | 1x 8-pin |
| Power consumption (max) | 145 W |
| Windows operating systems supported | Windows 10 x64, Windows 11 |
| Length | 220.5 mm |
| Depth | 41.6 mm |
| Height | 120.2 mm |
| Package width | 218 mm |
| Package depth | 83 mm |
| Package height | 283 mm |
| Package type | Box |
| Manual | Yes |
