GIGABYTE GeForce RTX 5060 EAGLE OC - 8GB GDDR7, 2550 MHz Boost, PCIe 5.0, HDMI 2.1b & 3x DP 2.1b (GV-N5060EAGLE-OC-8GD) (Boxed)
GeForce RTX 5060 EAGLE OC: 8GB GDDR7, 3840 CUDA cores, 2550 MHz boost clock (OC), PCIe 5.0, WINDFORCE 2X cooling. Supports DLSS 4 & Blackwell AI for 1080p/1440p gaming. HDMI 2.1b + 3x DP 2.1b, 550W PSU recommended.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| GPU (Graphics Cards) - Series | NVIDIA GeForce RTX |
|---|---|
| GPU (Graphics Cards) - PCIe Interface | PCIe 5.0 x16 |
| GPU (Graphics Cards) - Cooler Type | Dual Fan |
| GPU (Graphics Cards) - Color | Black |
| GPU (Graphics Cards) - Backplate | Yes |
| GPU (Graphics Cards) - VRAM Capacity | 8 GB |
| GPU (Graphics Cards) - VRAM Type | GDDR7 |
| GPU (Graphics Cards) - Outputs | DisplayPort 2.1 HDMI 2.1 |
| GPU (Graphics Cards) - Power Connector | 1x8-pin |
| GPU (Graphics Cards) - Card Length | Short (200-220 mm) |
Unlock superior 1080p and light 1440p gaming with the GIGABYTE GeForce RTX™ 5060 EAGLE OC 8G, powered by NVIDIA Blackwell architecture. Featuring 3840 CUDA cores, 8GB GDDR7 memory on a 128-bit bus at 28 Gbps, and a factory-overclocked boost clock of 2550 MHz, this GPU delivers smooth performance with DLSS 4 multi-frame generation and 5th-gen Tensor Cores for AI-enhanced visuals.
The WINDFORCE 2X cooling system with dual fans keeps temperatures low during intense sessions, while the compact FH/HL form factor (208 x 120 x 40 mm) fits most builds. It connects via PCIe 5.0 and requires a single 8-pin power connector, compatible with 550W PSUs. Enjoy 4K-ready outputs: 1x HDMI 2.1b and 3x DisplayPort 2.1b for up to four displays at 7680x4320.
- Key Technologies: DLSS 4, 4th-gen RT Cores, NVIDIA G-SYNC
- Cooling: Active WINDFORCE 2X, 2 fans
- Power & Size: 109W TDP, 2-slot, 540g
- Warranty: 3 years
| CUDA | Yes |
| CUDA cores | 3840 |
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 5060 |
| Processor frequency | 2550 MHz |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum displays per videocard | 4 |
| Discrete graphics card memory | 8 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 128 bit |
| Memory clock speed | 28000 MHz |
| Data transfer rate | 28 Gbit/s |
| Interface type | PCI Express 5.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| DisplayPort version | 2.1b |
| TV tuner integrated | No |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| Overclocked (OC) edition | Yes |
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 2X |
| Number of fans | 2 fan(s) |
| Form factor | Full-Height/Half-Length (FH/HL) |
| Product colour | Black |
| Minimum system power supply | 550 W |
| Supplementary power connectors | 1x 8-pin |
| Length | 208 mm |
| Depth | 40 mm |
| Height | 120 mm |
| Package type | Box |
| Quick installation guide | Yes |
| Products per shipping (inner) case | 1 pc(s) |
