Seasonic CORE GX-650 - 650W 80 PLUS Gold Fully-Modular ATX 3.1 PSU, 12V-2x6 (Boxed)
650W 80 PLUS Gold fully-modular ATX 3.1 PSU with native 12V-2x6 PCIe 5.1 cable, 120mm HDB fan, braided cables, Smart & Silent control, OptiSink design, 7-year warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 600 - 699 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12V-2x6 |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
The Seasonic CORE GX-650 complies with ATX 3.1 and PCIe 5.1 standards, featuring a native 12V-2x6 connector for up to 600W GPU power delivery. This 80 PLUS Gold certified fully modular PSU offers excellent efficiency, black braided cables, and optimal balance of cost and performance for PC builders.
Equipped with a 120mm Hydro Dynamic Bearing fan and Seasonic's Smart & Silent Fan Control, it ensures superior cooling at minimal noise. The innovative OptiSink design enhances heat dissipation with a redesigned PCB and compact components, allowing versatile installation orientations and eco-friendly operation.
Key benefits include full modularity for clean builds, robust protections, and a 7-year warranty. Ideal for mid-range gaming rigs with modern GPUs.
- ATX 3.1 / PCIe 5.1 compliant
- 1x 12V-2x6 PCIe connector
- Fully modular with braided cables
- 120mm HDB fan, hybrid fan control
- 80 PLUS Gold efficiency
- 140mm depth, 7-year warranty
| Total power | 650 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 9 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 648 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 54 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Over total voltage, Over voltage, Short circuit, Under voltage |
| Number of PATA power connectors | 2 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Operating temperature (T-T) | 0 - 50 °C |
| Cables included | AC, CPU, PCIe (12V-2x6), Peripheral (Molex) to SATA 3.3, SATA |
| Certification | BSMI, C-tick, CB, CCC, CE, cTUVus, EAC, FCC, TUV, UKCA |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Package type | Box |
| Fan bearing technology | Hydro Dynamic Bearing (HDB) |
| PCIe connectors | 1x 12V-2x6 (PCIe 5.1 compatible) |
| Warranty | 7 years |
