Enermax MaxPro IV - EMP750W - 750W Non-Modular ATX Power Supply, Black
750W Enermax MaxPro IV (EMP750W) non-modular ATX PSU, 80 PLUS certified, 120mm fan, 20+4 ATX, 4+4 EPS, four 6+2 PCIe connectors, OVP/UVP/OPP/SCP protection.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 750 W |
|---|---|
| PSU (Power Supplies) - Modularity | Non-modular |
| PSU (Power Supplies) - EPS CPU Connectors | 1x8-pin |
| PSU (Power Supplies) - Fan Size | 120 mm |
| PSU (Power Supplies) - Length | less than or equal to140 mm |
Enermax EMP750W. Total power: 750 W. AC input voltage: 200 - 240 V. AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX. Cabling type: Non-Modular. Purpose: PC. 80 PLUS certification: 80 PLUS. Mean time between failures (MTBF): 100000 h. Product colour: Black. Fan diameter: 12 cm. Width: 150 mm. Depth: 140 mm. Height: 86 mm
| Total power | 750 W |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 5 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 672 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 15 A |
| Max output current (+12V) | 56 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Power protection features | Over power. Over voltage. Short circuit. Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Feature | EPS power connector (4+4 pin) |
| PCI Express power connectors (6+2 pin) | 4 |
| Cabling type | Non-Modular |
| 80 PLUS certification | 80 PLUS |
| Purpose | PC |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Fan diameter | 12 cm |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
