Sharkoon Rebel P10 - 750W Fully-Modular ATX PSU - Cybenetics Silver, Black
750W fully-modular ATX 3.1 power supply, Cybenetics Silver, 24-pin ATX, 4+4 CPU connector, 4x PCIe 6+2, 5x SATA, sleeve-bearing fan, black finish.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Modularity | Fully modular |
|---|
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 9 / 4.5 A |
| Power Factor Correction (PFC) type | Active |
| Number of +12V rail(s) | 100 |
| Combined power (+3.3V) | 750 W |
| Combined power (+12V) | 100 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V1) | 62.5 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage |
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 55 cm |
| Number of SATA power connectors | 5 |
| Peripheral (Molex) power cable length | 480 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power cable length | 56 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 62 cm |
| ATX Power connector (24-pin) | Yes |
| PCI Express connector | Yes |
| Cabling type | Fully-Modular |
| 80 PLUS certification | No |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | Sleeve |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Cables included | AC |
| Certification | CE, FCC, CB |
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 1.66 kg |
| Sustainability certificates | ErP |
