Intel Core i9-14900KF - 24 Cores (8P+16E) 32 Threads, Up to 6.0 GHz, LGA1700, Boxed (No Cooler)
Intel Core i9-14900KF (boxed) — 24 cores (8 Performance + 16 Efficient), 32 threads, up to 6.0 GHz (Thermal Velocity Boost), P-core base 3.2 GHz, LGA1700, unlocked, no iGPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Core i9 |
|---|---|
| CPU (Processors) - Generation / Code name | Intel Raptor Lake Refresh |
| CPU (Processors) - Socket | LGA1700 |
| CPU (Processors) - Cores | 24 |
| CPU (Processors) - Threads | 32 |
| CPU (Processors) - TDP | 120-125 W |
| CPU (Processors) - Integrated Graphics | None |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core i9-14900KF. Processor family: Intel® Core™ i9. Processor socket: LGA 1700. Package type: Box. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. Market segment: Desktop. Use conditions: PC/Client/Tablet. PCI Express slots version: 4.0. 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.8 GHz. Intel® Thermal Velocity Boost Frequency: 6 GHz. Processor package size: 45 x 37.5 mm
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i9 (14th gen) |
| Processor model | i9-14900KF |
| Processor family | Intel® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Performance cores | 8 |
| Efficient cores | 16 |
| Processor boost frequency | 6 GHz |
| Performance-core boost frequency | 5.6 GHz |
| Performance-core base frequency | 3.2 GHz |
| Efficient-core boost frequency | 4.4 GHz |
| Efficient-core base frequency | 2.4 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Package type | Box |
| Processor base power | 125 W |
| Maximum turbo power | 253 W |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236787 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Feature | Intel® Standard Manageability (ISM) |
| Memory bandwidth (max) | 89.6 GB/s |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0. 5.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2020A |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.8 GHz |
| Intel® Thermal Velocity Boost Frequency | 6 GHz |
| Tjunction | 100 °C |
| Harmonized System (HS) code | 8542310001 |
| Launch date | Q4'23 |
| Status | Launched |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 32768 KB |
| Maximum internal memory | 192 GB |
