Intel Core Ultra 5 235 (Boxed) - 14-Core (6P+8E), 3.4GHz Base / 5.0GHz Boost, 24MB Cache, LGA1851, DDR5-6400
Boxed Intel Core Ultra 5 235 desktop CPU — 14 cores (6P+8E), 20 threads, 3.4GHz base up to 5.0GHz boost, 24MB Smart Cache, DDR5-6400 support, 65W base power.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Core Ultra 5 |
|---|---|
| CPU (Processors) - Generation / Code name | Intel Arrow Lake (desktop) |
| CPU (Processors) - Socket | LGA 1851 (Socket V1) |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Threads | 20 |
| CPU (Processors) - TDP | 65 W |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - PCIe Version | PCIe 5.0 |
| CPU (Processors) - Cooler Included | Yes |
Intel Core Ultra 5 235. Processor family: Intel Core Ultra 5. Processor socket: LGA 1851 (Socket V1). Package type: Box. Neural processor unit (NPU): Intel AI Boost. AI software frameworks supported by NPU: DirectML. OpenVINO. Windows ML. ONNX RT. WebNN. Total processor performance up to: 27 TOPs. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: Intel Graphics. On-board graphics card outputs supported: HDMI 2.1. Embedded DisplayPort (eDP) 1.4b. DisplayPort 2.1. On-board graphics card base frequency: 300 MHz. Market segment: Desktop. Use conditions: Workstation. PC/Client/Tablet. PCI Express slots version: 4.0. 5.0
| Processor manufacturer | Intel |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 235 |
| Processor family | Intel Core Ultra 5 |
| Processor cores | 14 |
| Processor socket | LGA 1851 (Socket V1) |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 5 GHz |
| Performance-core boost frequency | 5 GHz |
| Performance-core base frequency | 3.4 GHz |
| Efficient-core boost frequency | 4.4 GHz |
| Efficient-core base frequency | 2.9 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Package type | Box |
| Processor base power | 65 W |
| Maximum turbo power | 121 W |
| AI software frameworks supported by CPU | DirectML. OpenVINO. Windows ML. ONNX RT. WebNN |
| Maximum number of DMI lanes | 8 |
| Processor codename | Arrow Lake |
| Processor ARK ID | 241674 |
| Neural processor unit (NPU) | Intel AI Boost |
| Feature | Intel® Total Memory Encryption - Multi Key |
| AI software frameworks supported by NPU | DirectML. OpenVINO. Windows ML. ONNX RT. WebNN |
| Total processor performance up to | 27 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 6 TOPs |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 6400 MHz |
| Memory channels | Dual-channel |
| On-board graphics card model | Intel Graphics |
| On-board graphics card outputs supported | HDMI 2.1. Embedded DisplayPort (eDP) 1.4b. DisplayPort 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 2000 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card ID | 0x7D67 |
| Discrete graphics card model | Not available |
| Xe-cores | 3 |
| Market segment | Desktop |
| Use conditions | Workstation. PC/Client/Tablet |
| Maximum number of PCI Express lanes | 24 |
| PCI Express slots version | 4.0. 5.0 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| Direct Media Interface (DMI) Revision | 4.0 |
| Intel® Turbo Boost Technology | 2.0 |
| Maximum operating temperature | 105 °C |
| OpenCL version | 3.0 |
| Launch date | Q1'25 |
| Status | Launched |
| L2 cache | 26624 KB |
| Maximum internal memory | 192 GB |
| Graphics output | DP2.1 UHBR20. HDM2.1 FRL 12GHz. eDP1.4b |
