Intel Core i3-12100F 12th Gen 4C/8T 3.3GHz Base 4.3GHz Turbo LGA1700 (Boxed)
Intel Core i3-12100F: 12th Gen Alder Lake, 4 cores/8 threads, 3.3GHz base/4.3GHz turbo, LGA1700 socket, 12MB L3 cache, 58W TDP, no integrated GPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i3 |
| CPU (Processors) - Cores | 4 |
| CPU (Processors) - Threads | 8 |
| CPU (Processors) - TDP | 46-65W |
| CPU (Processors) - Integrated Graphics | No (Discrete GPU Required) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Core i3-12100F is a 12th generation Alder Lake desktop processor designed for budget-conscious builders and entry-level computing. With 4 performance cores and 8 threads enabled by Hyper-Threading technology, this processor delivers strong single-threaded performance and respectable multi-threaded capabilities. Operating at a base frequency of 3.3 GHz and boosting up to 4.3 GHz, the i3-12100F provides efficient performance for everyday computing, light gaming, and productivity tasks.
Built on Intel's advanced 10nm process technology, the i3-12100F features 12MB of shared L3 cache and supports both DDR4-3200 and DDR5-4800 memory standards through the LGA1700 socket. The processor has a thermal design power (TDP) of 58W under normal operation, with a maximum boost TDP of 89W. As the 'F' variant, this model does not include integrated graphics, requiring a discrete GPU for display output. The processor supports essential instruction set extensions including SSE4.1, SSE4.2, AVX2, and AES-NI, along with Intel's Turbo Boost 2.0 and Speed Shift technologies for dynamic performance optimization.
Key Features:
- 4 Performance Cores / 8 Threads with Hyper-Threading
- 3.3 GHz Base / 4.3 GHz Max Turbo Frequency
- 12MB Shared L3 Cache (80KB L1 + 1.28MB L2 per core)
- LGA1700 Socket (12th Gen Intel Platform)
- DDR4-3200 and DDR5-4800 Memory Support (2 Channels, up to 128GB)
- 10nm Process Technology
- 58W TDP / 89W Max Boost TDP
- No Integrated Graphics (Discrete GPU Required)
- Supports Turbo Boost 2.0, Speed Shift, and Enhanced SpeedStep
| Processor Family | Intel Core i3 (12th Generation Alder Lake) |
| Cores | 4 Performance Cores |
| Threads | 8 Threads (with Hyper-Threading) |
| Base Frequency | 3.3 GHz |
| Max Turbo Frequency | 4.3 GHz |
| L1 Cache | 4 x 32 KB Instruction + 4 x 48 KB Data (320 KB total) |
| L2 Cache | 4 x 1280 KB (5.12 MB total, 1.28 MB per core) |
| L3 Cache | 12 MB Shared |
| Socket | LGA1700 (FCLGA1700) |
| Fabrication Process | 10 nm (Intel 7) |
| Die Size | 163 mm² |
| TDP (PL1) | 58 W |
| Max Boost TDP (PL2) | 89 W |
| Maximum Core Temperature | 100°C |
| Bus Frequency | 100 MHz |
| Multiplier | 33x (Base), up to 43x (Turbo) |
| Unlocked Multiplier | No |
| Integrated Graphics | None (F-variant without UHD 730) |
| Memory Support | DDR4-3200, DDR5-4800 |
| Memory Channels | 2 |
| Max Memory Size | 128 GB |
| Max Memory Bandwidth | 76.8 GB/s |
| ECC Memory Support | No |
| Instruction Set Extensions | SSE4.1, SSE4.2, AVX, AVX2, AES-NI, TSX |
| Hyper-Threading | Yes |
| Turbo Boost Technology | Turbo Boost 2.0 |
| Turbo Boost Max 3.0 | No |
| Speed Shift (EIST) | Yes (Enhanced SpeedStep, Speed Shift) |
| Thermal Monitoring | Yes |
| Idle States | Yes |
| Deep Learning Boost | Yes |
| Cooler Included | No |
