Intel Core i5-14600K - 14th Gen Raptor Lake Refresh, 14 Cores (6P+8E), up to 5.3GHz, LGA1700 (Tray, No Cooler)
Intel Core i5-14600K (Tray) — 14 cores (6P+8E), 20 threads, up to 5.3 GHz turbo, 24 MB Smart Cache, LGA1700, DDR4/DDR5 support, Intel UHD 770. No cooler included.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Series / Family | Intel Core i5 |
|---|---|
| CPU (Processors) - Socket | LGA1700 |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Threads | 20 |
| CPU (Processors) - TDP | 120-125 W |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core i5-14600K. Processor family: Intel® Core™ i5. Processor socket: LGA 1700. Processor manufacturer: Intel. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770. On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1. On-board graphics card base frequency: 300 MHz. Market segment: Desktop. Use conditions: Workstation. PC/Client/Tablet. PCI Express slots version: 4.0. 5.0. Package type: Tray
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor model | i5-14600K |
| Processor family | Intel® Core™ i5 |
| Processor cores | 14 |
| Processor socket | LGA 1700 |
| Processor threads | 20 |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 5.3 GHz |
| Performance-core boost frequency | 5.3 GHz |
| Performance-core base frequency | 3.5 GHz |
| Efficient-core boost frequency | 4 GHz |
| Efficient-core base frequency | 2.6 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Processor base power | 125 W |
| Maximum turbo power | 181 W |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236799 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Feature | Intel® Standard Manageability (ISM) |
| Memory bandwidth (max) | 89.6 GB/s |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1550 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card ID | 0xA780 |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
| Multi-Format Codec Engines | 2 |
| Market segment | Desktop |
| Use conditions | Workstation. PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0. 5.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2020A |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Tjunction | 100 °C |
| OpenCL version | 3.0 |
| Launch date | Q4'23 |
| Status | Launched |
| Harmonized System (HS) code | 8542310001 |
| Package type | Tray |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 20480 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b. DP 1.4a. HDMI 2.1 |
