Intel Core i5-14600KF - 14th Gen Raptor Lake Refresh - 14 cores (6P+8E), 20T, up to 5.3 GHz, LGA1700, Unlocked
Intel Core i5-14600KF tray CPU — 14 cores (6P+8E) / 20 threads, P-core base 3.5 GHz, boost up to 5.3 GHz, 24 MB Smart Cache, LGA1700, 125W base power, no cooler, no iGPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Core i5 |
|---|---|
| CPU (Processors) - Generation / Code name | Intel Raptor Lake Refresh |
| CPU (Processors) - Socket | LGA1700 |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Threads | 20 |
| CPU (Processors) - TDP | 120-125 W |
| CPU (Processors) - Integrated Graphics | None |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - PCIe Version | PCIe 5.0 |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core i5-14600KF. Processor family: Intel® Core™ i5. Processor socket: LGA 1700. Processor manufacturer: Intel. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. Market segment: Desktop. Use conditions: PC/Client/Tablet. PCI Express slots version: 4.0. 5.0. Package type: Tray. Processor package size: 45 x 37.5 mm
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor model | i5-14600KF |
| Processor family | Intel® Core™ i5 |
| Processor cores | 14 |
| Processor socket | LGA 1700 |
| Processor threads | 20 |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 5.3 GHz |
| Performance-core boost frequency | 5.3 GHz |
| Performance-core base frequency | 3.5 GHz |
| Efficient-core boost frequency | 4 GHz |
| Efficient-core base frequency | 2.6 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Processor base power | 125 W |
| Maximum turbo power | 181 W |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236778 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 89.6 GB/s |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Feature | Intel® Standard Manageability (ISM) |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0. 5.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2020A |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Tjunction | 100 °C |
| Harmonized System (HS) code | 8542310001 |
| Package type | Tray |
| Launch date | Q4'23 |
| Status | Launched |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 20480 KB |
| Maximum internal memory | 192 GB |
