Poynting Antennas 5G LTE Mast A-LPDA-0092-LTE SET silber SMA (M) 2 x 11dBi SMA Male SET
Poynting LPDA-92. 11 dBi. 0.698-3.8 GHz. 50 Ohm. Richtantenne. SMA. Männlich
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Poynting LPDA-92. Antenne Zunahmeniveau (max): 11 dBi. Frequenzband: 0.698-3.8 GHz. Impedanz: 50 Ohm. Antennentyp: Richtantenne. Antenne Steckertyp: SMA. Steckerverbindergeschlecht: Männlich. Zertifizierung: MIL-STD 810G/ASTM B117. Breite: 200 mm. Tiefe: 1112 mm. Höhe: 47 mm. Verpackungsbreite: 210 mm. Verpackungstiefe: 1120 mm. Verpackungshöhe: 60 mm
| Frequenzband | 0.698-3.8 GHz |
| Impedanz | 50 Ohm |
| Antenne Zunahmeniveau (max) | 11 dBi |
| Antennentyp | Richtantenne |
| Antenne Steckertyp | SMA |
| Steckerverbindergeschlecht | Männlich |
| Polarisation | Lineare Polarisation |
| Produktfarbe | Silber |
| Internationale Schutzart (IP-Code) | IP65 |
| Überlebens-Windgeschwindigkeit | 160 km/h |
| Maximale Eingangsleistung | 10 W |
| Kabellänge | 7 m |
| Kabeltyp | HDF 195 |
| Montage | Stange |
| Zweck | Innen & Außen |
| Zertifizierung | MIL-STD 810G/ASTM B117 |
| Betriebstemperatur | -40 - 80 °C |
| Temperaturbereich bei Lagerung | -40 - 80 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 98% |
| Luftfeuchtigkeit bei Lagerung | 5 - 95% |
| Breite | 200 mm |
| Tiefe | 1112 mm |
| Höhe | 47 mm |
| Gewicht | 1.63 kg |
| Verpackungsbreite | 210 mm |
| Verpackungstiefe | 1120 mm |
| Verpackungshöhe | 60 mm |
| Paketgewicht | 2.02 kg |
| Menge pro Packung | 1 Stück(e) |
