Teltonika OTD140 - Outdoor 4G LTE Cat4 Router, IP55, Dual PoE Gigabit Ethernet
Rugged IP55 outdoor 4G LTE Cat4 router with integrated mount, RMS remote management support and two PoE-in/out Gigabit Ethernet ports for easy outdoor deployment.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The OTD140 outdoor router features a dedicated and durable IP55 plastic housing and an integrated mounting bracket, making this outdoor 4G router easy to deploy and capable of withstanding outdoor environmental conditions. Beyond that, this outdoor router is equipped with LTE Cat 4 connectivity, compatibility with RMS for remote management capabilities, and two PoE-in/out Ethernet ports.
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| SFP WAN | No |
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100Base-T(X) |
| Static route | Yes |
| VLAN support | Yes |
| Traffic control | Yes |
| Port forwarding | Yes |
| Auto MDI/MDI-X | Yes |
| Policy-based routing | Yes |
| Mobile network generation | 4G |
| 4G standard | LTE |
| Short Message Service (SMS) | Yes |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Wake-on-LAN ready | Yes |
| Reset button | Yes |
| WPS push button | No |
| Firmware upgradeable | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Fast Ethernet (copper) ports quantity | 2 |
| Power over Ethernet (PoE) ports quantity | 2 |
| DMZ support | Yes |
| Management protocols | FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS |
| VoIP protocols | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
| DHCP client | Yes |
| DHCP server | Yes |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL) |
| Security algorithms | HTTPS |
| Firewall | Yes |
| DoS attack prevention | Yes |
| ARP attack prevention | Yes |
| ICMP attack prevention | Yes |
| Access Control List (ACL) | Yes |
| Manual | Yes |
| Built-in processor | Yes |
| Processor frequency | 580 MHz |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
| Operating system installed | RutOS |
| Certification | CE, UKCA, EAC, UCRF, RCM |
| Product colour | White |
| Housing material | Plastic |
| Rack mounting | Yes |
| LED indicators | Status |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Power consumption (typical) | 2.5 W |
| Power consumption (max) | 6 W |
| Power source type | DC, PoE |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 100 mm |
| Depth | 235 mm |
| Height | 49.3 mm |
| Weight | 855 g |
| Input voltage | 42.5 - 57 V |
