TP-Link

TP-Link TL-WR840N - 300Mbps Single-Band (2.4 GHz) Wireless N Router - 4-Port Switch, Tabletop

SKU 7361 Brand TP-Link EAN13 6935364070533
300 Mbps Wireless N (802.11n) single-band 2.4 GHz tabletop router with 4 LAN ports and WPS security—ideal for HD streaming, VoIP and gaming.
Routers - Wi-Fi Standard Wi-Fi 4 (802.11n)
Routers - Bands Single-band (2.4 GHz)
Routers - LAN Ports 4

Highlights:
- 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work;
- Easy wireless security encryption at a push of WPS button;
- IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC;
- WDS wireless bridge provides seamless bridging to expand your wireless network.

What This Product Does
The 300Mbps Wireless N Router TL-WR840N is a combined wired/wireless network connection device designed specifically for small business and home office networking requirements. The TL-WR840N creates an exceptional and advanced wireless performance, making it ideal for streaming HD video, VoIP and online gaming. Also, Wi-Fi Protected Setup (WPS) button on the sleek and fashionable exterior ensures WPA2 encryptions, preventing the network from outside intrusions.

300Mbps Wireless N Speed - Fast Download Speed
TP-LINK’s TL-WR840N is a high speed solution that is compatible with IEEE 802.11b/g/n. Based on 802.11n technology, TL-WR840N gives users wireless performance at up to 300Mbps, which can meet your most demanding home networking needs, such as HD streaming, online gaming and large files downloading.

CCA Technology - Stable Wireless Signals
Clear Channel Assessment (CCA) automatically avoids channel conflicts using its clear channel selection feature and fully realizes the advantages of channel binding, greatly enhancing wireless performance.

IP QoS -- Manage your Bandwidth
Within the wireless network, indiscriminate Internet surfing and bandwidth-guzzling downloads by internal users often leave homes or small offices with insufficient bandwidth. TL-WR840N supports an IP QoS function, allowing optimum utilization of bandwidth and offering bandwidth control over congestion, preventing bandwidth abuse. In this way, users of a small network receive committed and specific bandwidth, preventing non-critical applications from degrading network performance.

Easy To Use
With the TL-WR840N even novice users can setup their networks. The device comes with a CD featuring an Easy Setup Assistant that leads users through the setup process step-by-step, and even helps with wireless network settings and security configurations.

Features:
- Wireless N speed of up to 300Mbps makes it ideal for bandwidth consuming or interruption sensitive applications like video streaming, online gaming and VoIP;
- 2T2R MIMO™ delivers greater throughput at range versus conventional 1T1R;
- Easily setup a WPA encrypted secure connection at a push of the QSS button;
- WDS wireless bridge provides seamless bridging to expand your wireless network;
- QoS function assures the quality of VoIP and multimedia streaming;
- Wi-Fi On/Off Button allows users to simply turn their wireless radio on or off;
- Features parental control function managing the internet access of children or employee's computer;
- Supports virtual server, special application and DMZ host ideal for creating a website within your LAN;
- Offers Auto-mail function for system log, convenient for managing the router;
- Backward compatible with 802.11b/g products;
- Easy Setup Assistant provides quick & hassle free installation;
- Sleek exterior, can be mounted on a wall or placed horizontally on a table or desk.


Ethernet WANYes
DSL WANNo
SIM card slotNo
3G/4G USB modem compatibilityNo
WAN connection typeRJ-45
Wi-Fi bandSingle-band (2.4 GHz)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LANYes
Ethernet LAN interface typeFast Ethernet
Ethernet LAN data rates10, 100 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Port forwardingYes
Port triggeringYes
Number of guest networks (2.4 GHz)1
VPN supportPPTP, L2TP, IPSec
Receiver sensitivity270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER
Ethernet LAN (RJ-45) ports4
USB portNo
DC-in jackYes
Web-based managementYes
Quality of Service (QoS) supportYes
Reset buttonYes
WPS push buttonYes
Security algorithmsWEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
FirewallYes
Firewall securitySPI
Guest accessYes
FilteringYes
MAC address filteringYes
URL filteringYes
DMZ supportYes
DHCP clientYes
DHCP serverYes
Universal Plug and Play (UPnP)Yes
Supported network protocolsIPv4, IPv6
Product colourGrey, White
LED indicatorsYes
On/off switchYes
Product typeTabletop router
Compliance certificatesRoHS, Federal Communications Commission (FCC), CE
Cables includedLAN (RJ-45)
AC adapter includedYes
Quick installation guideYes
Sustainability complianceYes
Antenna designExternal
Antenna gain level (max)5 dBi
Antennas quantity2
Built-in processorYes
Processor cores1
Power source typeDC
Output voltage9 V
Output current0.6 A
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supportedYes
Mac operating systems supportedYes
Width182 mm
Depth128 mm
Height35 mm
Package width265 mm
Package depth180 mm
Package height86 mm
Package weight430 g
WLAN data transfer rates supported11, 54, 300 Mbit/s
