Teltonika TSW101 - 5‑Port Gigabit PoE Switch (4x Passive PoE 30W, Metallic, IP30)
Teltonika TSW101 compact 5× Gigabit RJ45 switch with 4× passive PoE (30 W/port, 120 W total), DC 9–30 V, jumbo frames 9216, industrial -40–75°C, IP30 aluminum housing.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Teltonika TSW101. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries. Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3. IEEE 802.3az. IEEE 802.3u. Power connector: Terminal block (2-pin). Power over Ethernet (PoE)
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | Terminal block (2-pin) |
| Networking standards | IEEE 802.3. IEEE 802.3az. IEEE 802.3u |
| Feature | Power over Ethernet (PoE) |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Switching capacity | 10 Gbit/s |
| MAC address table | 2000 entries |
| Jumbo frames | 9216 |
| Product colour | Metallic |
| Housing material | Aluminium |
| LED indicators | Power. Status |
| International Protection (IP) code | IP30 |
| Power source | DC |
| Input voltage | 9 - 30 V |
| Power consumption (typical) | 0.64 W |
| Power consumption (max) | 2.31 W |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 120 W |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 115 mm |
| Depth | 32 mm |
| Height | 95 mm |
| Weight | 354 g |
| Certification | CE. REACH. RoHS. WEEETSW101 CETSW101 UKCATSW101 FCCTSW101 ICTSW101 CBTSW101 RCME-Mark |
| Harmonized System (HS) code | 851762 |
