Shelly Relais '1 Mini Gen. 3' WLAN BT max. 8A 1 Kanal Unterputz
Shelly 1 Mini Gen3. Intelligenter Schalter. 1P. Kabellos. Matt. 20 dBmW. 30 m
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Shelly 1 Mini Gen3. Typ: Intelligenter Schalter. Anzahl der Pole: 1P. Übertragungstechnik: Kabellos. AC Eingangsspannung: 110 - 240 V. Stromverbrauch (Standardbetrieb): 1.2 W. Maximale Schaltspannung (AC): 240 V. Breite: 35 mm. Tiefe: 16 mm. Höhe: 29 mm. Menge pro Packung: 1 Stück(e)
| Typ | Intelligenter Schalter |
| Anzahl der Pole | 1P |
| Übertragungstechnik | Kabellos |
| Oberflächentyp | Matt |
| Sendeleistung | 20 dBmW |
| Maximum Innenabstand | 30 m |
| Maximum Außenabstand | 50 m |
| Produktfarbe | Blau |
| Reihe von Modulen | 1 |
| Feature | Funktioniert mit Google Assistant |
| Bluethooth-Reichweite | 10 m |
| Bluetooth-Version | 4.2 |
| WLAN-Frequenz | 2.4 GHz |
| WLAN-Standards | 802.11b. 802.11g. Wi-Fi 4 (802.11n) |
| AC Eingangsspannung | 110 - 240 V |
| Stromverbrauch (Standardbetrieb) | 1.2 W |
| Maximale Schaltspannung (AC) | 240 V |
| Maximale Schaltspannung (DC) | 30 V |
| Maximaler Schaltstrom (AC) | 8 A |
| Maximaler Schaltstrom (DC) | 5 A |
| Maximale Lastleistung (AC) | 2000 W |
| Maximale Lastleistung (DC) | 150 W |
| Breite | 35 mm |
| Tiefe | 16 mm |
| Höhe | 29 mm |
| Gewicht | 19 g |
| Betriebstemperatur | -20 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 30 - 70% |
| Menge pro Packung | 1 Stück(e) |
