FSP NanoFit 800 800VA/480W UPS Standby LCD RJ45 6xSchuko (Boxed)
FSP NanoFit 800 Standby UPS: 800VA/480W, 6 Schuko outlets, RJ45 surge protection, LCD display, 12V/5Ah battery (14min full load). Compact black design with USB charging ports. Ideal for home/office backup.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| UPS & Power Backup - Product Type | UPS Unit |
|---|---|
| UPS & Power Backup - Power Capacity (VA) | 500 - 999 VA |
| UPS & Power Backup - Power Output (Watts) | Under 500 W |
| UPS & Power Backup - Topology | Standby (Offline) |
| UPS & Power Backup - Form Factor | Tower / Desktop |
| UPS & Power Backup - Input Plug | Schuko (Type F) |
| UPS & Power Backup - Output Receptacles | Schuko (Type F) |
| UPS & Power Backup - Outlets (Qty) | 6 |
| UPS & Power Backup - Special Features | LCD Display |
The FSP NanoFit 800 is a compact standby (offline) UPS designed for reliable power backup in home, gaming, or office environments. With 800VA/480W capacity, it provides 14 minutes of backup at full load using a 12V/5Ah sealed lead-acid battery. Featuring 6 surge-protected Schuko (Type F) outlets, 2 RJ45 network protection ports, and 2 USB-A charging ports (5V/1A max), it safeguards equipment from surges, spikes, and outages.
This black compact unit (305x158.5x95mm, 2.9kg net) includes a touch-sensitive LCD display showing input/output voltage, load level, battery capacity, and overload status in both AC and battery modes. It supports desktop or wall-mount installation, auto-restart on AC recovery, cold start function, and simulated sine wave output. Transfer time is typically 2-6ms with USB monitoring capability.
- ✅ 800VA/480W Standby UPS with simulated sine wave
- ✅ 6x Schuko outlets + 2x RJ45 surge protection
- ✅ LCD display + 2x USB charging ports
- ✅ Compact: 30.5x15.85x9.5cm, 2.9kg
- ✅ CE certified, 8h recharge time
| UPS Topology | Standby (Offline) |
| Capacity | 800VA / 480W |
| Output Voltage Regulation | ±10% |
| Output Frequency | 50/60Hz ±1Hz |
| Waveform | Simulated Sine Wave |
| Transfer Time | 2-6ms (Typical) |
| Input Voltage Range | 180-270 VAC |
| Battery Voltage | 12V |
| Battery Capacity | 5Ah x1 |
| Recharge Time | 8 hours (to 90%) |
| Full Load Backup Time | 14 min |
| AC Outlets | 6 x Schuko (Type F) |
| RJ45 Ports | 2 |
| USB Ports | 2 x Type-A (5V/1A charging) |
| Display Type | LCD (Touch) |
| Form Factor | Compact (Desktop/Wall Mount) |
| Product Color | Black |
| Dimensions (DxWxH) | 305 x 158.5 x 95 mm |
| Net Weight | 2.9 kg |
| Noise Level | <40 dB |
| Safety | CE |
| Operating Temperature | 0-40°C |
| Humidity | 0-90% RH (non-condensing) |
