Teltonika TSW114 - 5-Port Gigabit Unmanaged Switch, Black, Fanless, DIN & Wall-Mountable
Unmanaged 5-port Gigabit switch (5x 10/100/1000) with fanless aluminium housing, wall/DIN-rail mountable, IP30, wide temp -40–75°C, low power (max 2.3W).
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Network Switches - Fanless | Yes |
|---|
TSW114 is an affordable way to simplify your connectivity with its plug and play nature and 5 x Gigabit Ethernet ports that provide stable and reliable connectivity for high-bandwidth solutions. The switch has front-facing ports and an integrated DIN rail bracket to enable easy installation across many industrial environments - especially control cabinets.
| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| 10G support | No |
| MAC address table | 2000 entries |
| Jumbo frames support | Yes |
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| Housing material | Aluminium |
| LED indicators | LAN, Power |
| International Protection (IP) code | IP30 |
| Wall mountable | Yes |
| DIN rail mounting | Yes |
| Power source | DC |
| Power consumption (max) | 2.3 W |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 113.1 mm |
| Depth | 80.5 mm |
| Height | 27.4 mm |
| Weight | 174 g |
| Certification | CE, REACH, RoHS, WEEE UKCA, FCC, IC, CB, RCM |
