Teltonika TRB160 - Energy-Efficient LTE Cat 6 IoT Gateway - Steel, 128MB RAM, 256MB Flash, 1.2GHz Cortex-A7, USB-C
Ultra-small, energy-efficient IoT gateway with LTE Cat 6 (up to 300 Mbps), Gigabit Ethernet, USB-C power/data, SMA external antenna support, 128MB RAM.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The TRB160 is an ultra-small, lightweight, and energy-efficient IoT gateway equipped with mission-critical LTE Cat 6, Gigabit Ethernet, and a virtual network interface via USB Type-C for simultaneous powering and network data provision. This IoT gateway can reach cellular speeds of up to 300 Mbps with carrier aggregation in a broad range of applications and supports a wide range of industrial-grade protocols for M2M communication.
| Product colour | Steel |
| Enclosure material | Aluminium |
| International Protection (IP) code | IP30 |
| Enclosure International Protection (IP) code | IP30 |
| Antenna type | External |
| Antenna connector type | SMA |
| Antennas quantity | 1 |
| Short Message Service (SMS) | Yes |
| Control display unit | No |
| Built-in processor | Yes |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor model | Cortex-A7 |
| Processor frequency | 1200 MHz |
| Internal memory | 128 MB |
| Flash memory | 256 MB |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL) |
| Data link protocols | HTTP(S), MQTT, Azure MQTT, Kinesis |
| DMZ support | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| 4G LTE category | 4 |
| Mobile network generation | 4G |
| Data network | 3G, 4G |
| Cabling technology | 10/100/1000Base-T(X) |
| Dynamic DNS (DDNS) | Yes |
| Firewall security | Yes |
| VLAN support | Yes |
| Network address translation (NAT) | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| WAN connection | Ethernet (RJ-45) |
| Quality of Service (QoS) support | Yes |
| Power consumption (max) | 3.3 W |
| Input voltage | 5 V |
| Power over Ethernet (PoE) | Yes |
| DC input voltage | 9 - 30 V |
| Width | 74.2 mm |
| Depth | 83 mm |
| Height | 25 mm |
| Weight | 172 g |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
