Axis Industrial PoE Switch T8504-R
Axis 01633-001. Managed. Gigabit Ethernet (10/100/1000). Power over Ethernet (PoE)
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Axis 01633-001. Switch-Typ: Managed. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 4. Konsolen-Port: RJ-45. MAC-Adressentabelle: 8000 Eintragungen. Routing-/Switching-Kapazität: 16 Gbit/s. Netzstandard: IEEE 802.1Q. IEEE 802.1x. DC input Spannung: 54 - 57 V. Netzstecker: DC-Anschluss. Power over Ethernet (PoE)
| Switch-Typ | Managed |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 4 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Optischer Kabelverbinder | SFP |
| Konsolen-Port | RJ-45 |
| Netzstecker | DC-Anschluss |
| Netzstandard | IEEE 802.1Q. IEEE 802.1x |
| Feature | Montageblöcke enthalten |
| Routing-/Switching-Kapazität | 16 Gbit/s |
| Durchgang | 11.9 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Jumbo-Frames | 9216 |
| Unterstützte Sicherheitsalgorithmen | HTTPS. SNMP. SNMPv3 |
| Autentifizierungstyp | RADIUS |
| Produktfarbe | Schwarz |
| Gehäusematerial | Aluminium |
| DC input Spannung | 54 - 57 V |
| Anzahl Power over Ethernet (PoE) Anschlüsse | 4 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 60 W |
| Gesamtleistung Power over Ethernet (PoE) | 240 W |
| Betriebstemperatur | -40 - 75 °C |
| Temperaturbereich bei Lagerung | -40 - 85 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 95% |
| Breite | 62 mm |
| Tiefe | 130 mm |
| Höhe | 135 mm |
| Gewicht | 600 g |
| Warentarifnummer (HS) | 85176990 |
