TP-Link

TP-Link TL-SF1009P - 9-Port Fast Ethernet Unmanaged Switch, 8x PoE+ Ports, 65W Budget, Black

SKU 7683 Brand TP-Link EAN13 6935364052966
Unmanaged 9-port 10/100 switch with 8 PoE+ ports (total 65W). Fanless metal housing, wall-mountable, auto-negotiation and flow control, DC/PoE power, 0–40°C operating range.
Network Switches - Type Unmanaged
Network Switches - Port Speed 10/100 (Fast Ethernet)
Network Switches - PoE Budget 61-130 W
Network Switches - Rackmount No
Network Switches - Fanless Yes

Professional 9-Port Unmanaged Switch with 8 PoE+ Ports
Plug and Play, with PoE Transmission for Surveillance up to 250 m

Professional 9-Port Switch with 8-Port PoE+ (65 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 65 W PoE power budget* for the 8× PoE+ ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Ideal for IP Surveillance
—Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas.

**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.

Ideal for IP Surveillance
—Higher Performance and Security
Priority Mode and Isolation Mode make surveillance smoother and safer.

Intelligent Power Management
When total power consumption exceeds 65 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing
The interior components of TL-SF1009P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1009P delivers switching performance you can depend on.


Switch typeUnmanaged
Basic switching RJ-45 Ethernet ports quantity9
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Fast Ethernet (copper) ports quantity9
Power connectorDC-in jack
Networking standardsIEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Cable types supportedCat3, Cat4, Cat5, Cat5e
Full duplexYes
Half duplexYes
Flow control supportYes
Auto MDI/MDI-XYes
Auto-negotiationYes
MAC address auto-learning supportedYes
MAC address auto-aging supportedYes
Switching capacity1.6 Gbit/s
Forwarding rate1.3392 Mpps
MAC address table2000 entries
Store-and-forwardYes
Rack mountingNo
StackableNo
Product colourBlack
Housing materialMetal
LED indicatorsActivity, Link, PoE, Power
Wall mountableYes
FanlessYes
Power sourceDC/PoE
Power supply includedNo
AC input voltage220 V
AC input frequency50 Hz
DC input voltage53.5 V
Input current1.31 A
Power consumption (max)77.08 W
Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity8
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget65 W
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Heat dissipation262.84 BTU/h
Width171 mm
Depth98 mm
Height27 mm
User guideYes
AC adapter includedYes
Package typeBox
Package width223 mm
Package depth280 mm
Package height68 mm
Package weight980 g
Sustainability complianceYes
Compliance certificatesFederal Communications Commission (FCC), CE, RoHS
CertificationFCC, CE, RoHS
Harmonized System (HS) code85176990
