ARCTIC P12 Pro Reverse A-RGB 120mm Case Fan - Reverse Blade - PWM - 3000 RPM (Boxed)
ARCTIC P12 Pro Reverse 120mm case fan with reverse blade design, 3000 RPM PWM control, 73 CFM airflow, 4.5 mmH2O static pressure, A-RGB lighting, and fluid dynamic bearing for quiet cooling.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Cooling (CPU & Case) - Device Type | Case Fan |
|---|---|
| Cooling (CPU & Case) - Fan Size | 120 mm |
| Cooling (CPU & Case) - Lightning | RGB |
| Cooling (CPU & Case) - Connector | 4-Pin PWM |
| Cooling (CPU & Case) - Color | Black |
| Cooling (CPU & Case) - Special Features | Daisy-Chain Low Noise Reverse Blade |
Reverse Airflow Design
The ARCTIC P12 Pro Reverse is specifically engineered with reverse blade orientation, drawing air from the back side of the fan. This unique design is ideal for glass-fronted PC cases and modern builds where conventional fans would compromise aesthetics. The transparent reverse blades allow RGB lighting to shine through while maintaining high performance.
High Static Pressure & Optimized Airflow
With 73 CFM (124 m³/h) airflow and 4.5 mmH2O static pressure, this fan efficiently penetrates dense radiators, narrow perforated panels, and mesh structures. The trumpet-shaped inlet and tear-drop shaped struts minimize turbulence and aerodynamic noise. Featuring a fluid dynamic bearing (FDB) combined with an extended shaft, the P12 Pro Reverse delivers quiet operation while maintaining excellent cooling performance across its 500-3000 RPM range.
Premium Features & Easy Installation
The fan includes 12x A-RGB Gen2 LEDs for customizable lighting, PWM control with complete stop below 5% PWM, and daisy-chain connectors for synchronized multi-fan control. Minimal gaps between blade ring and frame, automatic balancing, and high-precision manufacturing ensure smooth, vibration-free operation. Backed by a 6-year warranty and compatible with most modern PC cases.
- Fan Speed: 500–3000 RPM (PWM controlled, 0 RPM below 5% PWM)
- Airflow: 73 CFM | 124 m³/h
- Static Pressure: 4.5 mmH2O
- Bearing Type: Fluid Dynamic Bearing (FDB)
- Connector: 4-Pin PWM + 4-Pin RGB Socket
- Dimensions: 120 x 120 x 27 mm
- Weight: 172 g (fan only)
- Warranty: 6 Years
| Device Type | Case Fan |
| Fan Size | 120 mm |
| Fan Speed | 500–3000 RPM (PWM controlled) |
| Minimum Speed | 0 RPM below 5% PWM |
| Airflow | 73 CFM | 124 m³/h |
| Static Pressure | 4.5 mmH2O |
| Fan Bearing | Fluid Dynamic Bearing (FDB) |
| Blade Design | Reverse Blade |
| Dimensions | 120 (L) x 120 (W) x 27 (H) mm |
| Net Weight | 172 g |
| Typical Voltage | 12 V DC |
| Start-Up Voltage | 3.5 V DC |
| Current | 0.4 A |
| Connector Type | 4-Pin PWM Fan Plug + 4-Pin RGB Socket |
| Cable Length | 400 mm + 80 mm Daisy-Chain Cable |
| RGB LEDs | 12x A-RGB Gen2 LEDs |
| RGB Connector | 5V Digital RGB (4-Pin Socket) |
| Daisy-Chain Support | Yes (PST - Synchronized PWM Control) |
| Operating Temperature | 0–40 °C |
| Warranty | 6 Years |
| Special Features | Reverse airflow design, trumpet-shaped inlet, tear-drop struts, minimal gap design, automatic balancing, vibration-damping, low noise operation |
