ind. Netzteil POW-2432 24VDC 75W DIN-Schiene si
LevelOne 24V DC Industrie-Netzteil. 75W. DIN-Schiene.-20 ~ +70 ℃. 75 W. 90 - 264 V. 47 - 63 Hz. 1.45 A. 16 ms. Überspannung. Überlastschutz. Kurzschluß
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne 24V DC Industrie-Netzteil. 75W. DIN-Schiene.-20 ~ +70 ℃. Gesamtleistung: 75 W. AC Eingangsspannung: 90 - 264 V. AC Eingangsfrequenz: 47 - 63 Hz. Mittlere Betriebsdauer zwischen Ausfällen (MTBF): 486200 h. Produktfarbe: Blau. Silber. Sicherheit: EN 55032 (CISPR32) Class A EN 61000-3-2.-3.EACTPTC020.CNS13438 Class A EN 61000-4-2.3.4.5.6.8.11.... Breite: 32 mm. Tiefe: 102 mm. Höhe: 125.2 mm
| Gesamtleistung | 75 W |
| AC Eingangsspannung | 90 - 264 V |
| AC Eingangsfrequenz | 47 - 63 Hz |
| Eingangsstrom | 1.45 A |
| Haltezeit | 16 ms |
| Energieschutzeigenschaften | Überspannung. Überlastschutz. Kurzschluß |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 486200 h |
| Produktfarbe | Blau. Silber |
| Anzahl Lüfter | 0 Lüfter |
| Betriebstemperatur | -20 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 90% |
| Sicherheit | EN 55032 (CISPR32) Class A EN 61000-3-2.-3.EACTPTC020.CNS13438 Class A EN 61000-4-2.3.4.5.6.8.11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) |
| Breite | 32 mm |
| Tiefe | 102 mm |
| Höhe | 125.2 mm |
| Gewicht | 430 g |
| Verpackungsbreite | 53 mm |
| Verpackungstiefe | 132 mm |
| Verpackungshöhe | 147 mm |
| Paketgewicht | 700 g |
| Verpackungsart | Box |
| Anzahl Kartons pro Palette | 20 Stück(e) |
| Breite des Versandkartons | 282 mm |
| Länge des Versandkartons | 313 mm |
| Höhe des Versandkartons | 393 mm |
| Gewicht Versandkarton | 19.6 kg |
| Warentarifnummer (HS) | 8504403090 |
| Ursprungsland | China |
| Spannungstoleranz | 1% |
| Ausgang Spannung (Note) | 24V |
