Switch 24x GE GEP-2652 2xGSFP 19' 370W 24xPoE+
LevelOne GEP-2652. Managed. L2. Gigabit Ethernet (10/100/1000). Power over Ethernet (PoE). Rack-Einbau
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne GEP-2652. Switch-Typ: Managed. Switch-Ebene: L2. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 24. Konsolen-Port: RJ-45. MAC-Adressentabelle: 8000 Eintragungen. Netzstandard: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ag. IEEE 802.1p. IEEE 802.1s. IEEE 802.1v. IEEE 802.1w. IEEE.... Netzstecker: AC-Eingangsbuchse. Power over Ethernet (PoE). Rack-Einbau
| Switch-Typ | Managed |
| Switch-Ebene | L2 |
| Feature | Ressourcen-CD |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 24 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Anzahl Gigabit Ethernet (Kupfer) Anschlüsse | 24 |
| Menge SFP-Modul-Steckplätze | 2 |
| Konsolen-Port | RJ-45 |
| Netzstecker | AC-Eingangsbuchse |
| Netzwerk-Virtualisierungstechnologien | Q-in-Q Tunneling |
| QinQ-Implementierung | Selective QinQ |
| Virtuelle LAN-Funktionen | MAC address-based VLAN. Port-based VLAN. Protocol-based VLAN. Tagged VLAN. VLAN Identifier ( VLAN ID). Voice VLAN |
| Anzahl der VLANs | 4000 |
| Transferrate | 38.69 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Jumbo-Frames | 9000 |
| Datenpaket-Pufferspeicher | 128 MB |
| DHCP-Funktionen | DHCP snooping |
| Unterstützte Sicherheitsalgorithmen | SNMPv3 |
| Authentifizierung | Gast VLAN. Webbasierte Authentifizierung |
| Autentifizierungstyp | RADIUS |
| Warteschleifenplanungs-Algorithmen | Priority queuing (PQ). Weighted Round Robin (WRR) |
| Multicast Listener Discovery (MLD) Snooping | v1/v2 |
| IPv4 & IPv6-Funktionen | IPv6 Telnet |
| Produktfarbe | Grau |
| Gehäusematerial | Metall |
| LED-Anzeigen | Link. PoE. Leistung |
| Speicherkapazität | 8 MB |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Eingangsstrom | 6.5 A |
| Stromverbrauch (max.) | 435 W |
| Anzahl Power over Ethernet (PoE) Anschlüsse | 24 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 370 W |
| Betriebstemperatur | 0 - 45 °C |
| Temperaturbereich bei Lagerung | -40 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Luftfeuchtigkeit bei Lagerung | 5 - 90% |
| Breite | 440 mm |
| Tiefe | 208 mm |
| Höhe | 44 mm |
| Gewicht | 3.87 kg |
| Mitgelieferte Kabel | AC |
| Verpackungsart | Box |
| Verpackungsbreite | 555 mm |
| Verpackungstiefe | 295 mm |
| Verpackungshöhe | 88 mm |
| Paketgewicht | 4.2 kg |
| Konformitätsbescheinigungen | RoHS |
| Zertifizierung | CE |
| Ursprungsland | China |
| Warentarifnummer (HS) | 85176990 |
