Seasonic FOCUS GX-1000 ATX 3.0 1000W Fully Modular 80+ Gold (Boxed)
1000W ATX 3.0/3.1 PSU, 80+ Gold certified, fully modular with 140mm depth. Features 135mm FDB fan, hybrid control (fanless/silent/cooling), 1x12V-2x6 + 3x6+2 PCIe for high-end GPUs. 10-year warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 1000 - 1199 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12V-2x6 3x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
Seasonic FOCUS GX-1000 ATX 3.0
Upgraded to ATX 3.1 & PCIe 5.1 standards, this 1000W fully modular PSU fits 140mm depth chassis. Powers latest high-end GPUs/CPUs with 1x 12V-2x6 (600W) + 3x 6+2 PCIe connectors, 1x 4+4 EPS for CPUs. 80 PLUS Gold efficiency peaks ~93%, low ripple/suppression.
Premium Digital Hybrid Fan Control with Fanless, Silent, Cooling modes via rear button. 135mm Fluid Dynamic Bearing fan ensures quiet operation (Cybenetics A-, ~28dBA avg). OptiSink PCB boosts heat dissipation 8x for reliability. Japanese capacitors, 0-50°C operation, 10-year warranty.
- ✅ Fully modular flat cables reduce clutter
- ✅ Excellent load regulation & transient response
- ✅ OPP/OCP/OVP/OTP/SC/UVP protections
- ✅ Compact ATX: 150x140x86mm
- ✅ MTBF 100,000 hours
| Total power | 1000 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| 80 PLUS certification | 80 PLUS Gold |
| Cabling type | Fully-Modular |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | FDB |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
| Depth | 140 mm |
| Width | 150 mm |
| Height | 86 mm |
| Warranty period | 10 year(s) |
| Combined power (+12V) | 996 W |
| Max output current (+12V) | 83 A |
| PCI Express power connectors (12+4 pin) | 1 |
| PCI Express power connectors (6+2 pin) | 3 |
| CPU power connector (4+4 pin) | Yes |
| Mean time between failures (MTBF) | 100000 h |
| Operating temperature (T-T) | 0 - 50 °C |
| Compliance certificates | CB, CE, EAC, REACH, RoHS, WEEE, cTUVus |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
