Lenovo ThinkPad Docking Station - 40AY0090EU - USB-C Dock, HDMI + 2×DisplayPort, 3×USB-A, 1×USB-C, Gigabit Ethernet, Black
USB-C docking station (40AY0090EU) with HDMI + 2×DisplayPort for up to 3 displays at 3840×2160, 3×USB-A, 1×USB-C, Gigabit Ethernet, combo audio jack, 90W power.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Docks & Hubs - Type | USB-C Dock |
|---|---|
| Docks & Hubs - Host Interface | USB-C (DP Alt-Mode) |
| Docks & Hubs - Video Outputs | HDMI + DP |
| Docks & Hubs - Max Displays | 3 |
| Docks & Hubs - Ethernet | 1GbE |
| Docks & Hubs - USB Ports | USB-A + USB-C |
| Docks & Hubs - Card Reader | None |
| Docks & Hubs - Audio Jack | Yes |
| Docks & Hubs - OS Compatibility | Windows |
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Card reader integrated | No |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Number of displays supported | 3 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| On/off switch | Yes |
| Certification | FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM |
| Power source type | USB |
| Power connector | USB Type-C |
| Power supply | 90 W |
| Windows operating systems supported | Windows 10, Windows 7 |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Width | 171 mm |
| Depth | 80 mm |
| Height | 30.8 mm |
| Weight | 340 g |
| Quantity per pack | 1 pc(s) |
| Package width | 210 mm |
| Package depth | 158 mm |
| Package height | 75 mm |
| Package weight | 955 g |
| Cables included | USB Type-C |
| Compliance certificates | CE |
| Harmonized System (HS) code | 84733020 |
