Lenovo ThinkPad Hybrid USB-C Dock 40AF0135EU 2xHDMI 2xDP (Boxed)
Lenovo ThinkPad Hybrid USB-C Dock 40AF0135EU: 2x HDMI, 2x DisplayPort (dual 4K@60Hz), 135W charging, Gigabit Ethernet, 7 USB ports. Ideal for multi-monitor enterprise setups with USB-A/C compatibility.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| USB Hubs & Docking Stations - Host Interface | USB-A USB-C |
|---|---|
| USB Hubs & Docking Stations - Number of Ports | 8 |
| USB Hubs & Docking Stations - Downstream Ports | USB-A USB-C |
| USB Hubs & Docking Stations - Video Output | DisplayPort HDMI |
| USB Hubs & Docking Stations - Power Delivery | 140W+ |
| USB Hubs & Docking Stations - Ethernet | 1 Gbps |
| USB Hubs & Docking Stations - Special Features | Audio Jack External Power Supply Kensington Lock Slot MST Support |
The Lenovo ThinkPad Hybrid USB-C with USB-A Dock (40AF0135EU) is a versatile docking station designed for enterprise environments with mixed laptop fleets. It connects via USB-C (with included USB-A adapter) and expands your notebook with extensive connectivity, supporting up to dual UHD 4K@60Hz displays through 2x HDMI 2.0 and 2x DisplayPort 1.4 ports.
Featuring 135W rapid charging via included Slim Tip AC adapter, three USB 3.2 Gen 2 ports (10Gbps, one always-on), USB-C 10Gbps, USB 2.0, Gigabit Ethernet, and 3.5mm audio combo jack. Enterprise features include PXE boot, Wake-on-LAN, and MAC address pass-through for simplified IT management. Perfect for shared desks or multi-monitor productivity.
- ✅ Dual 4K video output (2x HDMI + 2x DP)
- ✅ 135W power delivery for ThinkPad charging
- ✅ Gigabit RJ45 Ethernet + 3.5mm audio
- ✅ 7x USB ports (USB-C/A mix, 10Gbps speeds)
- ✅ Kensington lock slot for security
- ✅ Includes 135W AC adapter and USB-A dongle
| Product Type | Docking Station |
| Model | 40AF0135EU |
| Docking Interface | USB-C with USB-A Dongle |
| Power Adapter | 135W Slim Tip AC Adapter |
| Video Ports | 2x DisplayPort 1.4 (4K@60Hz), 2x HDMI 2.0 (4K@60Hz) |
| Max Displays | Up to 2x UHD 4K@60Hz |
| USB Ports | 1x USB-C 10Gbps (5V/3A), 3x USB-A 3.2 Gen2 10Gbps (1x Always-On), 2x USB-A 2.0 |
| Ethernet | 1x RJ45 Gigabit (1Gbps) |
| Audio | 1x 3.5mm Stereo/Mic Combo Jack |
| Dimensions (Dock) | 210 x 80 x 30 mm |
| Boxed Dimensions | 270 x 165 x 88 mm |
| Weight (Boxed) | 1.35 kg |
