Lenovo ThinkPad Thunderbolt 4 Dock 40B00300EU - TB4 HDMI2.1 2xDP1.4 300W (Boxed)
Thunderbolt 4 Workstation Dock 40B00300EU: HDMI 2.1, 2x DP1.4, supports 8K@30Hz or 4x4K@60Hz, 40Gbps, Gigabit Ethernet, 4xUSB-A, 1xUSB-C, 230W PD, 300W PSU, VESA, Kensington. (187 chars)
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| USB Hubs & Docking Stations - Host Interface | Thunderbolt 4 |
|---|---|
| USB Hubs & Docking Stations - Number of Ports | 8 |
| USB Hubs & Docking Stations - Downstream Ports | USB-A USB-C |
| USB Hubs & Docking Stations - Video Output | DisplayPort HDMI |
| USB Hubs & Docking Stations - Power Delivery | 140W+ |
| USB Hubs & Docking Stations - Ethernet | 1 Gbps |
| USB Hubs & Docking Stations - Special Features | Audio Jack External Power Supply Kensington Lock Slot MST Support |
The Lenovo ThinkPad Thunderbolt 4 Workstation Dock (40B00300EU) delivers premium connectivity for workstations and laptops. It supports breathtaking 8K@30Hz resolution or up to four 4K@60Hz displays via HDMI 2.1, 2x DisplayPort 1.4, and Thunderbolt downstream port. Enjoy lightning-fast 40Gbps data transfer speeds and Intel vPro/AMT support for remote management.
Equipped with 4x USB 3.2 Gen 2 Type-A ports (one always-on), 1x USB-C 3.2 Gen 2, Gigabit Ethernet with PXE/WOL, and 3.5mm combo audio jack. Provides up to 230W Power Delivery via 300W Slim Tip PSU, compatible with Thunderbolt 3/4, USB4, and USB-C systems. Features VESA mount, dual Kensington lock slots for security.
- Video: 1x HDMI 2.1, 2x DP 1.4, 1x TB Downstream
- USB: 4x USB-A 3.2 Gen2, 1x USB-C 3.2 Gen2 (5V/3A)
- Network: 1x RJ45 Gigabit Ethernet
- Power: 300W adapter, 230W PD to host
- Dimensions: 220x80x30mm, Weight: 0.45kg (dock only)
| Connectivity technology | Wired |
| Host interface | Thunderbolt 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 230 W |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Thunderbolt 4 ports quantity | 1 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Card reader integrated | No |
| Data transfer rate | 40 Gbit/s |
| HD type | 8K Ultra HD |
| Maximum digital resolution | 7680 x 4320 pixels |
| Number of displays supported | 4 |
| Maximum refresh rate | 30 Hz |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Product colour | Black, Red |
| LED indicators | Yes |
| Certification | cULus, FCC, ICES, NOM |
| Built-in speaker(s) | No |
| Power supply | 300 W |
| Output voltage | 20 V |
| Output current | 15 A |
| Power consumption (max) | 230 W |
| Windows operating systems supported | Windows 10 |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Width | 220 mm |
| Depth | 80 mm |
| Height | 30 mm |
| Weight | 450 g |
| Quantity per pack | 1 pc(s) |
| Package width | 270 mm |
| Package depth | 195 mm |
| Package height | 85 mm |
| Package weight | 1.9 kg |
| Warranty card | Yes |
| Cables included | AC |
| AC adapter included | Yes |
| Harmonized System (HS) code | 84733020 |
