ind. Netzteil POW-2442 24VDC 120W DIN-Schiene si
LevelOne 24V DC Industrie-Netzteil. 120W. DIN-Schiene.-20 ~ +70 ℃. 120 W. 90 -264 V. 47 - 63 Hz. 2.25 A. 16 ms. Überlastschutz. Überspannung. Kurzschluß
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne 24V DC Industrie-Netzteil. 120W. DIN-Schiene.-20 ~ +70 ℃. Gesamtleistung: 120 W. AC Eingangsspannung: 90 -264 V. AC Eingangsfrequenz: 47 - 63 Hz. Mittlere Betriebsdauer zwischen Ausfällen (MTBF): 2636800 h. Produktfarbe: Blau. Silber. Sicherheit: EN 55032 (CISPR32) Class A EN 61000-3-2.-3.EACTPTC020.CNS13438 Class A EN 61000-4-2.3.4.5.6.8.11.... Breite: 40 mm. Tiefe: 113.5 mm. Höhe: 125.2 mm
| Gesamtleistung | 120 W |
| AC Eingangsspannung | 90 -264 V |
| AC Eingangsfrequenz | 47 - 63 Hz |
| Eingangsstrom | 2.25 A |
| Haltezeit | 16 ms |
| Energieschutzeigenschaften | Überlastschutz. Überspannung. Kurzschluß |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 2636800 h |
| Produktfarbe | Blau. Silber |
| Anzahl Lüfter | 0 Lüfter |
| Betriebstemperatur | -20 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 90% |
| Breite | 40 mm |
| Tiefe | 113.5 mm |
| Höhe | 125.2 mm |
| Gewicht | 530 g |
| Verpackungsbreite | 60 mm |
| Verpackungstiefe | 140 mm |
| Verpackungshöhe | 143 mm |
| Paketgewicht | 700 g |
| Verpackungsart | Box |
| Anzahl Kartons pro Palette | 20 Stück(e) |
| Breite des Versandkartons | 310 mm |
| Länge des Versandkartons | 310 mm |
| Höhe des Versandkartons | 305 mm |
| Gewicht Versandkarton | 14 kg |
| Warentarifnummer (HS) | 8504403090 |
| Ursprungsland | China |
| Spannungstoleranz | 1% |
| Ausgang Spannung (Note) | 24V |
| Stromstärke (maximal) | 5 A |
