Switch 8x GE IGP-1271 4xGSFP 240W 8xPoE+
LevelOne IGP-1271. Managed. L3. Gigabit Ethernet (10/100/1000). Power over Ethernet (PoE)
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne IGP-1271. Switch-Typ: Managed. Switch-Ebene: L3. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 16. Konsolen-Port: RJ-45. MAC-Adressentabelle: 8000 Eintragungen. Routing-/Switching-Kapazität: 24 Gbit/s. Netzstandard: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1ag. IEEE 802.1p. IEEE 802.1s. IEEE 802.1w. IEEE.... DC input Spannung: 48 - 57 V. Power over Ethernet (PoE)
| Switch-Typ | Managed |
| Switch-Ebene | L3 |
| Feature | Ressourcen-CD |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 16 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Menge SFP-Modul-Steckplätze | 4 |
| Konsolen-Port | RJ-45 |
| Kupfer Ethernet Verkabelungstechnologie | 100BASE-TX. 1000BASE-T |
| Virtuelle LAN-Funktionen | Private VLAN. Voice VLAN. Protocol-based VLAN. MAC address-based VLAN. IP subnet–based VLAN |
| Routing-/Switching-Kapazität | 24 Gbit/s |
| Transferrate | 17.856 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Jumbo-Frames | 9216 |
| Datenpaket-Pufferspeicher | 0.5 MB |
| DHCP-Funktionen | DHCP server. DHCP snooping. DHCP relay. DHCP client |
| Management-Protokolle | SNMP. Web. Telnet. SSH |
| Unterstützte Netzwerkprotokolle | IPv4/IPv6 |
| Produktfarbe | Grau |
| LED-Anzeigen | Alarm. Leistung. Ring. Status. System |
| Internationale Schutzart (IP-Code) | IP30 |
| Sicherheit | UL. CB |
| Speicherkapazität | 128 MB |
| Flash-Speicher | 32 MB |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 476206 h |
| DC input Spannung | 48 - 57 V |
| Stromverbrauch (max.) | 239.2 W |
| Energieschutzeigenschaften | Kurzschluß |
| Anzahl Power over Ethernet plus (PoE+) Anschlüsse | 8 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 240 W |
| Betriebstemperatur | -40 - 75 °C |
| Temperaturbereich bei Lagerung | -40 - 85 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Luftfeuchtigkeit bei Lagerung | 10 - 90% |
| Wärmeableitung | 816.18 BTU/h |
| Breite | 62 mm |
| Tiefe | 130 mm |
| Höhe | 135 mm |
| Gewicht | 700 g |
| Mitgelieferte Kabel | LAN (RJ-45) |
| Verpackungsbreite | 255 mm |
| Verpackungstiefe | 207 mm |
| Verpackungshöhe | 85 mm |
| Paketgewicht | 900 g |
| Zertifizierung | RoHSFCC.CEEN61000-4-2EN61000-4-3EN61000-4-4EN61000-4-5EN61000-4-6IEC60068-2-32IEC60068-2-27IEC60068-2-6 |
| Ursprungsland | Taiwan |
| Breite des Versandkartons | 520 mm |
| Länge des Versandkartons | 445 mm |
| Höhe des Versandkartons | 220 mm |
| Warentarifnummer (HS) | 85176990 |
| Gewicht Versandkarton | 2.4 kg |
| Anzahl Produkte pro Versandkarton | 10 Stück(e) |
