Teltonika ATRM50 - Rugged 5G Transport Router, 4x M12 Gigabit LAN, Dual SIM/eSIM, GNSS, EN45545-2 & EN50155
Rugged 5G automotive router with 4x M12 Gigabit Ethernet, M12 power, dual SIM + eSIM failover, GNSS and RMS-compatible remote management; railway-certified.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The ATRM50 is a rugged 5G router built for transportation, featuring 4 x M12 Gigabit Ethernet ports and M12 power input for durable, secure connections. It delivers ultra-high cellular speeds up to 3.4 Gbps and supports dual SIM with eSIM™ for seamless failover. Certified to EN 45545-2 and EN 50155 standards, the ATRM50 is engineered to meet the rigorous safety and reliability requirements of railway systems—while also being a strong fit for other demanding transportation environments. The router comes with GNSS, an integrated mounting bracket, and is compatible with RMS for efficient on-site and remote management.
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | Yes |
| WAN connection type | RJ-45 |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s, IEEE 802.11v, IEEE 802.11w, IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| Full duplex | Yes |
| Auto-sensing | Yes |
| Port forwarding | Yes |
| Load balancing system | Yes |
| VPN support | OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale |
| Mobile network generation | 5G |
| Dual SIM support | Yes |
| 4G standard | LTE |
| 4G LTE category | 19 |
| 5G standard | Sub6 NSA, Sub6 SA |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Web-based management | Yes |
| Web-based setup wizard | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| MU-MIMO technology | Yes |
| Cloud-managed | Yes |
| Command-line interface (CLI) | Yes |
| Security algorithms | AES-CCMP, EAP-TLS, OWE, PEAP, TKIP, WPA-PSK, WPA2-EAP, WPA2-Enterprise, WPA2-PSK, WPA3-EAP, WPA3-SAE |
| Firewall | Yes |
| Access Control List (ACL) | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Product colour | Black |
| Housing material | Aluminium |
| Wall mountable | Yes |
| International Protection (IP) code | IP30 |
| Indication light | Yes |
| LED indicators | LTE, Link, Power, Status, WAN |
| On/off switch | No |
| Built-in display | No |
| Product type | Industrial router |
| Antenna included | Yes |
| Mounting kit | Yes |
| Quick installation guide | Yes |
| Quick start guide | Yes |
| Antenna design | External |
| Antennas quantity | 7 |
| Built-in processor | Yes |
| Processor manufacturer | MediaTek |
| Processor model | MIPS1004KC |
| Processor frequency | 880 MHz |
| Processor cores | 2 |
| Internal memory | 256 MB |
| Internal memory type | DDR3 |
| Flash memory | 16 MB |
| Power source type | DC |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 167 mm |
| Depth | 113 mm |
| Height | 47 mm |
| Weight | 550 g |
