Gigabyte GA-X870 A Tachyon ICE - AM5 E-ATX Motherboard - DDR5 128GB, PCIe 4.0, Dual 2.5/5GbE, RGB
AM5 E-ATX motherboard for AMD Ryzen 7000/8000/9000. DDR5 support up to 128GB (2 slots), PCIe 4.0 x16, dual 2.5/5GbE LAN, onboard RGB lighting.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - Memory Slots | 2 |
|---|---|
| Motherboards - Max Memory Capacity | 128 GB |
| Motherboards - Main Slot PCIe Version | PCIe 4.0 |
| unterstützte Prozessormodelle | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Sockel | Sockel AM5 |
| Chipsatz | AMD X870 |
| BIOS | UEFI AMI |
| Formfaktor | Erweitertes ATX |
| geeignet für freien Multiplikator | ja |
| Speicher max. | 128 GB |
| Memory slots | 2 |
| Speicher je Speicherplatz | 64 GB |
| Storage type | DDR5-SDRAM |
| RAM Takt | 9600,9200,8800,8600,8400,8200,8000,7800,7600,7200,7000,6800,6666,6600,6400,6200,6000,5600,5200,4800,4400 MHz |
| Speicher Kanäle | Zweikanalig |
| Speichertyp | non-ECC;un-buffered |
| Controller in CPU | ja |
| LAN (RJ45) | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Schnelles Ethernet, Gigabit Ethernet |
| PS/2 (Tastatur/Maus) | 2 |
| USB 3.1 | 3 |
| USB 3.0 | 4 |
| USB 2.0 | 0 |
| VGA | 0 |
| DVI | 1 |
| HDMI | 1 |
| DisplayPort | 0 |
| Mikrofon | 1 |
| Line-Out 3,5 mm Klinke | 5 |
| PCIe 4.0 | 1 |
| PCIe 3.0 | 0 |
| PCIe 2.0 | 1x PCIe x16;3x PCIe x1 |
| Mainbord Strom | 24pin |
| CPU Strom | 8+4pin |
| SATA 3 | 2 |
| M.2 | 3 |
| M.2 Länge max. | 110mm |
| M.2 Konnektor | M |
| USB-Header USB 2.0 | 2 |
| USB-Header USB 3.0 | 1 |
| USB-Header USB C | 0 |
| Lüfter 4-polig PWM | 6 |
| Sound-Chip | 7.1 Kanäle |
| LAN | Realtek RTL8126 |
| Multi-GPU Modus | Nicht unterstützt |
| RAID SATA | 0, 1, 5, 10 |
| Beleuchtungsfarbe | RGB LED |
| Farbe | schwarz |
| Gewicht (g) | 3,32 kg |
| Breite (cm) | 30.40 |
| Tiefe (cm) | 24.30 |
| Internal graphic | yes |
| verfügbare Slots | 6 |
