Switch 26x GE XQS-3126 2x40 100GbE 19' 185W 24xPoE
LevelOne 26-Port L3 Managed TOR-Fiberswitch. 24x 1/10GbE SFP+. 2x 40/100GbE QSFP28. Hot-Swap Redundante Stromversorgung. Managed. L3. Rack-Einbau
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne 26-Port L3 Managed TOR-Fiberswitch. 24x 1/10GbE SFP+. 2x 40/100GbE QSFP28. Hot-Swap Redundante Stromversorgung. Switch-Typ: Managed. Switch-Ebene: L3. Anzahl USB 2.0 Anschlüsse: 1. Konsolen-Port: RJ-45. MAC-Adressentabelle: 128000 Eintragungen. Routing-/Switching-Kapazität: 880 Gbit/s. Netzstandard: IEEE 802.1AE. IEEE 802.1D. IEEE 802.1ag. IEEE 802.1s. IEEE 802.1w. IEEE 802.3ah. IEEE 802.3az. Rack-Einbau
| Switch-Typ | Managed |
| Switch-Ebene | L3 |
| Feature | Gummifüße |
| Menge Modul-Steckplätze SFP+ | 24 |
| Anzahl der Management-Ports | 1 Stück(e) |
| Konsolen-Port | RJ-45 |
| Anzahl QSFP28-Ports | 2 |
| Anzahl USB 2.0 Anschlüsse | 1 |
| Netzstandard | IEEE 802.1AE. IEEE 802.1D. IEEE 802.1ag. IEEE 802.1s. IEEE 802.1w. IEEE 802.3ah. IEEE 802.3az |
| Virtuelle LAN-Funktionen | Private VLAN. Protocol-based VLAN |
| Anzahl der VLANs | 4000 |
| VLAN-Zuordnungstyp | 1:1-VLAN-Mapping. N: 1-VLAN-Mapping |
| Routing-/Switching-Kapazität | 880 Gbit/s |
| Transferrate | 660 Mpps |
| MAC-Adressentabelle | 128000 Eintragungen |
| Jumbo-Frames | 16000 |
| Datenpaket-Pufferspeicher | 4.5 MB |
| DHCP-Funktionen | DHCP Option 82. DHCP snooping |
| Autentifizierungstyp | IEEE 802.1x. RADIUS. TACACS+ |
| Warteschleifenplanungs-Algorithmen | SP. WRR+SP. Weighted Round Robin (WRR). Weighted random early detection (WRED) |
| Multicast-Funktionen | Multicast traffic suppression |
| Router Protokoll | BGP. BGP4+. HSRP. MPLS. OSPF. OSPFv3. RIP-1. RIP-2. RIPng. VRRP |
| Produktfarbe | Schwarz |
| Speicherkapazität | 2048 MB |
| Flash-Speicher | 4096 MB |
| Geräuschpegel | 57 dB |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 200000 h |
| Energiequelle | AC |
| Anzahl von Stromversorgungseinheiten | 2 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 Hz |
| Stromverbrauch (Standardbetrieb) | 26 W |
| Stromverbrauch (max.) | 64 W |
| Betriebstemperatur | -10 - 50 °C |
| Temperaturbereich bei Lagerung | -20 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Luftfeuchtigkeit bei Lagerung | 5 - 95% |
| Wärmeableitung | 238.91 BTU/h |
| Breite | 442.5 mm |
| Tiefe | 300 mm |
| Höhe | 44.5 mm |
| Gewicht | 4.25 kg |
| Mitgelieferte Kabel | AC |
| Verpackungsbreite | 576 mm |
| Verpackungstiefe | 448 mm |
| Verpackungshöhe | 94 mm |
| Paketgewicht | 7.45 kg |
| Anzahl der Kartons pro Palette (Luft) | 18 Stück(e) |
| Palettenlänge (brutto) | 100 cm |
| Palettenbreite (brutto) | 120 cm |
| Palettenhöhe (Luft) | 164.9 cm |
| Konformitätsbescheinigungen | Eidgenössische Kommunikationskommission (FCC). RoHS. UKCA |
| Ursprungsland | China |
| Breite des Versandkartons | 605 mm |
| Länge des Versandkartons | 462 mm |
| Höhe des Versandkartons | 215 mm |
| Warentarifnummer (HS) | 851762 |
| Gewicht Versandkarton | 15.7 kg |
| Anzahl Produkte pro Versandkarton | 2 Stück(e) |
