Switch 8x GE GEP-1051 2xGSFP 70W 8xPoE
LevelOne GEP-1051. Managed. L2/L3/L4. Gigabit Ethernet (10/100/1000). Power over Ethernet (PoE). Rack-Einbau
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne GEP-1051. Switch-Typ: Managed. Switch-Ebene: L2/L3/L4. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 8. MAC-Adressentabelle: 8000 Eintragungen. Routing-/Switching-Kapazität: 20 Gbit/s. Netzstandard: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1p. IEEE 802.1s. IEEE 802.1w. IEEE 802.3. IEEE 802.3ab. IEEE.... Power over Ethernet (PoE). Rack-Einbau
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3/L4 |
| Feature | Ressourcen-CD |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 8 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Menge SFP-Modul-Steckplätze | 2 |
| Kupfer Ethernet Verkabelungstechnologie | 10BASE-T. 100BASE-TX. 1000BASE-T |
| Virtuelle LAN-Funktionen | Tagged VLAN. Port-based VLAN |
| Ethernet-Kabel Verkablungstechnologie | 1000BASE-X |
| Routing-/Switching-Kapazität | 20 Gbit/s |
| Transferrate | 14.9 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Anzahl Queues | 8 |
| Jumbo-Frames | 10000 |
| Datenpaket-Pufferspeicher | 4.1 MB |
| DHCP-Funktionen | DHCP client |
| Zugriffskontrollliste (ACL) Eingang | 256 |
| Unterstützte Sicherheitsalgorithmen | SSH. SSH-2. SSL/TLS |
| Autentifizierungstyp | HWTACACS+. RADIUS |
| Warteschleifenplanungs-Algorithmen | Weighted Round Robin (WRR) |
| Management-Protokolle | SNMP v1/v2c/v3. Telnet |
| IPv4 & IPv6-Funktionen | IPv6 ping. IPv6 tracert. IPv6 Telnet. Dual stack IPv4/IPv6 |
| Produktfarbe | Schwarz |
| LED-Anzeigen | Aktivität. Link. Leistung. System |
| Sicherheit | UL |
| Speicherkapazität | 16 MB |
| Geräuschpegel | 0 dB |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 118824 h |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Stromverbrauch (Standardbetrieb) | 80 W |
| Anzahl Power over Ethernet plus (PoE+) Anschlüsse | 8 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 70 W |
| Betriebstemperatur | 0 - 50 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Wärmeableitung | 267.95 BTU/h |
| Breite | 294 mm |
| Tiefe | 180 mm |
| Höhe | 44 mm |
| Gewicht | 2 kg |
| Mitgelieferte Kabel | AC |
| Verpackungsart | Box |
| Verpackungsbreite | 375 mm |
| Verpackungstiefe | 270 mm |
| Verpackungshöhe | 85 mm |
| Paketgewicht | 2.18 kg |
| Zertifizierung | CE class A. FCC. VCCI. BSMI |
| Ursprungsland | China |
| Warentarifnummer (HS) | 85176990 |
