Hanwha Techwin IP-Cam Zbh. Recorder XRN-1620SB1 0TB PoE 16 Kanal
Hanwha XRN-1620SB1. 16 Kanäle. 3840 x 2160 Pixel. 3840 x 2160. 1920x1080. H.265. H.264. MJPEG. G.711. G.726. AAC. 140 Mbit/s
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Hanwha XRN-1620SB1. Video-Eingangskanäle: 16 Kanäle. Maximale Auflösung: 3840 x 2160 Pixel. Unterstütze Auflösung: 3840 x 2160. 1920x1080. Max. Speicherkapazität: 24 TB. HDD Schnittstelle: SATA. SATA II. SATA III. Ethernet LAN Datentransferraten: 10.100.1000 Mbit/s. Netzstandard: IEEE 802.3af. IEEE 802.3at. Unterstützte Netzwerkprotokolle: IPv4. IPv6. TCP/IP. UDP/IP. RTP (UDP). RTP (TCP). RTSP. NTP. HTTP. DHCP (Server. Client). SMTP..... Produktfarbe: Schwarz. Stromverbrauch (max.): 310 W. AC Eingangsspannung: 100 - 240 V. AC Eingangsfrequenz: 50 - 60 Hz
| Video-Eingangskanäle | 16 Kanäle |
| Alarm-Eingangskanäle | 4 |
| Alarm-Ausgangskanäle | 2 |
| Maximale Auflösung | 3840 x 2160 Pixel |
| Unterstütze Auflösung | 3840 x 2160. 1920x1080 |
| Video-Codec | H.265. H.264. MJPEG |
| Audio-Codec | G.711. G.726. AAC |
| Feature | Reset-Knopf |
| Eingangsbandbreite | 140 Mbit/s |
| Ausgangsbandbreite | 32 Mbit/s |
| Audio-System | 2-Wege |
| HDD Kapazität | 0 GB |
| Maximale unterstützte Anzahl der HDD | 4 |
| Max. Speicherkapazität | 24 TB |
| HDD Schnittstelle | SATA. SATA II. SATA III |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 18 |
| Ethernet LAN Datentransferraten | 10.100.1000 Mbit/s |
| Anzahl Power over Ethernet (PoE) Anschlüsse | 16 |
| Anzahl HDMI-Anschlüsse | 1 |
| VGA (D-Sub)-Ausgangsanschlüsse | 1 |
| Anzahl USB 2.0 Anschlüsse | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 1 |
| Audio-RCA-Ausgänge | 1 |
| Netzstandard | IEEE 802.3af. IEEE 802.3at |
| Produktfarbe | Schwarz |
| Stromverbrauch (max.) | 310 W |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 200 W |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 20 - 85% |
| Breite | 440 mm |
| Tiefe | 428.4 mm |
| Höhe | 89.8 mm |
| Gewicht | 5.76 kg |
