KVM Extender KVM-9036 over IP 2xUSB
LevelOne KVM over Cat.5 Extender. Sender und Empfänger. Kabelgebunden. 100 m. Cat5. Cat5e. 1920 x 1200 Pixel. Tastenkombination. Drucktasten
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne KVM over Cat.5 Extender. Typ: Sender und Empfänger. Übertragungstechnik: Kabelgebunden. Maximal mögliche Übertragungsstrecke: 100 m. Transmitter-Video-Anschlusstyp: VGA. Transmitter lokaler Video-Anschlusstyp: VGA. Transmitter lokaler Tastatur-/Maus-Anschlusstyp: USB. Empfänger lokaler Video-Anschlusstyp: VGA. Empfänger lokale Tastatur/Maus-Anschlusstyp: USB. USB-Port-Typ: USB Typ-B. Breite des Senders: 13.1 cm. Tiefe des Senders: 6.5 cm. Höhe des Senders: 2.6 cm
| Typ | Sender und Empfänger |
| Übertragungstechnik | Kabelgebunden |
| Maximal mögliche Übertragungsstrecke | 100 m |
| unterstütze Kabeltypen | Cat5. Cat5e |
| Auflösung (maximal. analog) | 1920 x 1200 Pixel |
| KVM port Auswahl | Tastenkombination. Drucktasten |
| Feature | Upgradefähige Firmware |
| Produktfarbe | Schwarz |
| Material | Metall |
| Transmitter-Video-Anschlusstyp | VGA |
| Transmitter lokaler Video-Anschlusstyp | VGA |
| Transmitter lokaler Tastatur-/Maus-Anschlusstyp | USB |
| Anzahl RJ-45-Anschlüsse (Sender) | 1 |
| Empfänger lokaler Video-Anschlusstyp | VGA |
| Empfänger lokale Tastatur/Maus-Anschlusstyp | USB |
| Anzahl RJ-45-Anschlüsse (Empfänger) | 1 |
| USB-Port-Typ | USB Typ-B |
| Anzahl USB 2.0 Anschlüsse | 2 |
| Breite des Senders | 13.1 cm |
| Tiefe des Senders | 6.5 cm |
| Höhe des Senders | 2.6 cm |
| Gewicht Transmitter | 586 g |
| Breite des Receivers | 13.1 cm |
| Tiefe des Receivers | 6.5 cm |
| Höhe des Receivers | 2.6 cm |
| Receivergewicht | 586 g |
| Verpackungsbreite | 204 mm |
| Verpackungstiefe | 176 mm |
| Verpackungshöhe | 139 mm |
| Paketgewicht | 1.69 kg |
| Mitgelieferte Kabel | KVM |
| Betriebstemperatur | 0 - 40 °C |
| Temperaturbereich bei Lagerung | -5 - 65 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 95% |
| Luftfeuchtigkeit bei Lagerung | 5 - 95% |
| Konformitätsbescheinigungen | CE. Eidgenössische Kommunikationskommission (FCC). UKCA. WEEE |
| Ursprungsland | Taiwan |
| Palettenlänge (brutto) | 94 cm |
| Palettenbreite (brutto) | 135 cm |
| Palettenhöhe (brutto) | 11.5 cm |
| Breite des Versandkartons | 440 mm |
| Länge des Versandkartons | 370 mm |
| Höhe des Versandkartons | 430 mm |
| Gewicht Versandkarton | 21.3 kg |
| Anzahl Produkte pro Versandkarton | 12 Stück(e) |
