Intel Core i7-14700 LGA1700 20-Core (8P+12E) 5.4GHz DDR4/DDR5 (Tray)
Intel Core i7-14700 14th gen desktop processor with 20 cores (8P+12E), 28 threads, up to 5.4 GHz, DDR4/DDR5 support, integrated UHD Graphics 770, LGA1700 socket, 65W base TDP.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i7 |
| CPU (Processors) - Cores | 20 |
| CPU (Processors) - Threads | 28 |
| CPU (Processors) - TDP | 46-65W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Core i7-14700 is a 14th generation Raptor Lake Refresh desktop processor featuring a hybrid architecture with 8 performance cores and 12 efficiency cores for a total of 20 cores and 28 threads. With a base frequency of 2.1 GHz and boost up to 5.4 GHz, this processor delivers excellent performance for both single-threaded and multi-threaded workloads, making it ideal for content creation, gaming, and professional applications.
This processor supports both DDR4 and DDR5 memory with dual-channel configuration, providing up to 192 GB maximum memory capacity and 89.6 GB/s memory bandwidth. The integrated Intel UHD Graphics 770 with 32 execution units and 256 shaders enables 4K display support via DisplayPort 1.4a, eDP 1.4b, and HDMI 2.1. Built on Intel's 10nm process technology and utilizing the LGA1700 socket, it features 33 MB L3 cache and 28 MB L2 cache. The processor operates at 65W base TDP with a maximum turbo power of 219W and includes support for PCIe 4.0 and 5.0, Intel Turbo Boost Max 3.0, and advanced instruction sets including AVX-2, SSE4.1, and SSE4.2.
Key specifications and features:
- 20 cores (8 Performance + 12 Efficiency), 28 threads
- Base/Turbo frequencies: 2.1 GHz / 5.4 GHz (P-cores), 1.5 GHz / 4.2 GHz (E-cores)
- 33 MB L3 Cache + 28 MB L2 Cache
- DDR4-3200 and DDR5-5600 support, up to 192 GB
- Intel UHD Graphics 770 (32 EUs, 256 shaders)
- LGA1700 socket, 10nm process
- 65W base TDP, 219W turbo PL2
- PCIe 4.0/5.0, Hyper-Threading, Turbo Boost Max 3.0
- Tray packaging (cooler not included)
| Processor Manufacturer | Intel |
| Processor Generation | Intel Core i7 (14th Gen) |
| Processor Model | i7-14700 |
| Processor Family | Intel Core i7 |
| Total Cores | 20 (8 Performance + 12 Efficiency) |
| Total Threads | 28 |
| Performance-Core Base Frequency | 2.1 GHz |
| Performance-Core Boost Frequency | 5.4 GHz |
| Efficiency-Core Base Frequency | 1.5 GHz |
| Efficiency-Core Boost Frequency | 4.2 GHz |
| L1 Cache | 20 x 32 KB (Instruction) + 20 x 48 KB (Data) |
| L2 Cache | 28 MB |
| L3 Cache | 33 MB |
| Processor Socket | LGA 1700 |
| Manufacturing Process | 10 nm |
| Base TDP | 65 W |
| Maximum Turbo Power (PL2) | 219 W |
| Maximum Junction Temperature | 100 °C |
| Integrated Graphics | Intel UHD Graphics 770 |
| GPU Execution Units | 32 |
| GPU Shaders | 256 |
| GPU Base Frequency | 300 MHz |
| GPU Maximum Frequency | 1600 MHz |
| GPU DirectX Support | 12.0 |
| GPU OpenGL Support | 4.5 |
| Maximum Displays Supported | 4 |
| GPU Video Outputs | eDP 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| Maximum DisplayPort Resolution | 7680 x 4320 @ 60 Hz |
| Maximum HDMI Resolution | 4096 x 2160 @ 60 Hz |
| Memory Type Support | DDR4-3200, DDR5-5600 |
| Memory Channels | Dual-Channel (2) |
| Maximum Memory Capacity | 192 GB |
| Maximum Memory Bandwidth | 89.6 GB/s (DDR5), 51.2 GB/s (DDR4) |
| ECC Memory Support | Yes |
| PCIe Lanes | 20 (PCIe 4.0 and 5.0) |
| PCIe Configurations | 1x16+1x4, 2x8+1x4 |
| Direct Media Interface (DMI) | DMI 4.0 (8 lanes) |
| Instruction Set Extensions | SSE4.1, SSE4.2, AVX, AVX-2, AES-NI |
| Hyper-Threading | Yes |
| Turbo Boost Technology | Turbo Boost 2.0, Turbo Boost Max 3.0 |
| Enhanced SpeedStep (EIST) | Yes |
| Speed Shift | Yes |
| Virtualization Support | VT-x, VT-x EPT, VT-d |
| Thermal Monitoring | Yes |
| Idle States | Yes |
| Package Type | Tray |
| Processor Package Dimensions | 45 x 37.5 mm |
| Operating Systems Supported | Windows 10, Windows 11, Linux |
| Launch Date | Q1 2024 |
| Processor Status | Launched |
| Intel ARK ID | 236781 |
| Cooler Included | No |
| Overclocking Support | No (Multiplier Locked) |
