Intel Xeon W7-2495X - 24C/48T, 2.5 GHz (4.8 GHz Turbo), LGA4677, DDR4, Tray
Workstation CPU Intel Xeon W7-2495X — 24 cores / 48 threads, 2.5 GHz base, up to 4.8 GHz Turbo, quad-channel DDR4 support, LGA4677 socket, tray package.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Xeon W |
|---|---|
| CPU (Processors) - Cores | 24 |
| CPU (Processors) - Threads | 48 |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - Cooler Included | No |
Intel Xeon w7-2495X. Processor family: Intel Xeon W. Processor socket: LGA 4677 (Socket E). Package type: Tray. Memory channels: Quad-channel. Maximum internal memory supported by processor: 2 TB. Memory types supported by processor: DDR4-SDRAM. Market segment: Workstation. Use conditions: Workstation. Supported instruction sets: SSE4.1. AMX. SSE4.2. AVX 2.0. AVX-512. Intel® Turbo Boost Max Technology 3.0 frequency: 4.8 GHz. Intel® Turbo Boost Technology 2.0 frequency: 4.6 GHz. Intel® QuickAssist Technology (QAT): 0 default devices. Processor package size: 77.5 x 56.5 mm
| Processor manufacturer | Intel |
| Processor model | w7-2495X |
| Processor base frequency | 2.5 GHz |
| Processor family | Intel Xeon W |
| Processor cores | 24 |
| Processor socket | LGA 4677 (Socket E) |
| Processor threads | 48 |
| System bus rate | 0 GT/s |
| Processor operating modes | 64-bit |
| Performance cores | 24 |
| Processor boost frequency | 4.8 GHz |
| Processor cache | 45 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 225 W |
| Maximum turbo power | 270 W |
| Stepping | S3 |
| Bus type | DMI4 |
| Processor codename | Sapphire Rapids |
| Processor ARK ID | 233416 |
| Maximum internal memory supported by processor | 2 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Quad-channel |
| Feature | Intel® Advanced Matrix Extensions (AMX) |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Workstation |
| Use conditions | Workstation |
| Maximum number of PCI Express lanes | 64 |
| PCI Express slots version | 5.0 |
| Supported instruction sets | SSE4.1. AMX. SSE4.2. AVX 2.0. AVX-512 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G180729 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.8 GHz |
| Intel® Turbo Boost Technology 2.0 frequency | 4.6 GHz |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® QuickAssist Technology (QAT) | 0 default devices |
| Intel® Dynamic Load Balancer (DLB) | 0 default devices |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® In-memory Analytics Accelerator (IAA) | 0 default devices |
| Tcase | 77 °C |
| DTS Max | 94 °C |
| Launch date | Q1'23 |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Memory speed (max) | 4800 MHz |
| Package carrier | E1B |
| Harmonized System (HS) code | 8542310001 |
| Processor package size | 77.5 x 56.5 mm |
| Maximum internal memory | 2 TB |
