Intel Core i9-14900 LGA1700 Tray 14th Gen 24C/32T up to 5.8GHz UHD 770
Intel Core i9-14900 14th Gen tray CPU: LGA1700, 24 cores (8P+16E), 32 threads, up to 5.8GHz turbo, UHD Graphics 770, DDR4/DDR5, 65W base/219W turbo.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i9 |
| CPU (Processors) - Cores | 24 |
| CPU (Processors) - Threads | 32 |
| CPU (Processors) - TDP | 46-65W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Core i9-14900 is a high-performance 14th Gen Raptor Lake Refresh desktop processor in tray packaging (no retail box or cooler included). It features 24 cores (8 Performance-cores + 16 Efficient-cores) and 32 threads, with max turbo frequency up to 5.8 GHz via Thermal Velocity Boost. Designed for LGA1700 socket motherboards, it supports DDR4 and DDR5 memory up to 192GB dual-channel at 89.6 GB/s bandwidth.
Integrated Intel UHD Graphics 770 enables up to 4 displays with HDMI 2.1, DisplayPort 1.4a, and eDP 1.4b outputs. Ideal for gaming, content creation, and workstations with 36MB Smart Cache, PCIe 5.0/4.0 support (20 lanes), and technologies like Turbo Boost Max 3.0. Base power 65W, max turbo power 219W, Tjunction 100°C. Launched Q1 2024.
- Socket: LGA 1700
- Cores/Threads: 24 (8P+16E)/32
- Max Frequency: 5.8 GHz
- Integrated Graphics: UHD 770 (4 displays)
- Memory: DDR4/DDR5 up to 192GB
- TDP: 65W (219W turbo)
- Packaging: Tray (no cooler)
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i9 (14th gen) |
| Processor model | i9-14900 |
| Processor family | Intel® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Performance cores | 8 |
| Efficient cores | 16 |
| Processor boost frequency | 5.8 GHz |
| Performance-core boost frequency | 5.4 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core boost frequency | 4.3 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236793 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory channels | Dual-channel |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1650 MHz |
| Number of displays supported (on-board graphics) | 4 |
| Market segment | Desktop |
| PCI Express slots version | 4.0, 5.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.6 GHz |
| Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
| Tjunction | 100 °C |
| Launch date | Q1'24 |
| Status | Launched |
