Intel Xeon E-2378G - 8C/16T 2.8GHz (5.1GHz Turbo) - LGA1200, 80W, Tray
Intel Xeon E-2378G server CPU: 8 cores / 16 threads, 2.8 GHz base, 5.1 GHz Turbo, LGA1200, DDR4 support up to 128 GB, Intel UHD P750 iGPU, tray (no cooler).
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Xeon E |
|---|---|
| CPU (Processors) - Socket | LGA1200 |
| CPU (Processors) - Cores | 8 |
| CPU (Processors) - Threads | 16 |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Xeon E-2378G. Processor family: Intel Xeon E. Processor socket: LGA 1200 (Socket H5). Processor lithography: 14 nm. Memory channels: Dual-channel. Maximum internal memory supported by processor: 128 GB. Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel UHD Graphics P750. Maximum on-board graphics card memory: 64 GB. On-board graphics card base frequency: 350 MHz. Market segment: Server. PCI Express configurations: 1x16+1x4. 2x8+1x4. 1x8+3x4. Supported instruction sets: SSE4.1. SSE4.2. AVX 2.0. AVX-512. Intel® Turbo Boost Technology 2.0 frequency: 5.1 GHz. Maximum Enclave Size Support for Intel® SGX: 0.5 GB
| Processor manufacturer | Intel |
| Processor model | E-2378G |
| Processor base frequency | 2.8 GHz |
| Processor family | Intel Xeon E |
| Processor cores | 8 |
| Processor socket | LGA 1200 (Socket H5) |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Processor threads | 16 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 5.1 GHz |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 80 W |
| Package type | Tray |
| Processor ARK ID | 212262 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Feature | Intel® vPro™ Platform Eligibility |
| On-board graphics card model | Intel UHD Graphics P750 |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1300 MHz |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
| Market segment | Server |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4. 1x8+3x4 |
| Supported instruction sets | SSE4.1. SSE4.2. AVX 2.0. AVX-512 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 5.1 GHz |
| Maximum Enclave Size Support for Intel® SGX | 0.5 GB |
| Tjunction | 100 °C |
| Launch date | Q3'21 |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Servicing status | Baseline Servicing |
| Harmonized System (HS) code | 85423119 |
| Processor package size | 37.5 x 37.5 mm |
| Maximum internal memory | 128 GB |
