LANCOM XS-3510YUP Managed L3-Lite multi-gigabit PoE++ access switch 4x 1GE PoE+ 802.3at 4x 10GE PoE++ 802.3bt type 4 ...
LANCOM XS-3510YUP. Managed. L2/L3. 2.5G Ethernet (100/1000/2500). Power over Ethernet (PoE). Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LANCOM XS-3510YUP. Switch-Typ: Managed. Switch-Ebene: L2/L3. Basic Switching RJ-45 Ethernet Ports-Typ: 2.5G Ethernet (100/1000/2500). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 8. Konsolen-Port: RJ-45. MAC-Adressentabelle: 16000 Eintragungen. Netzstandard: IEEE 802.1D. IEEE 802.1s. IEEE 802.1w. IEEE 802.3af. IEEE 802.3at. IEEE 802.3bt. Netzstecker: AC-Eingangsbuchse. Power over Ethernet (PoE). Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3 |
| Feature | Betriebsanleitung |
| MIB Unterstützung | MIB II. Bridge MIB. Interface MIB. SMON MIB. IGMP MIB |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 8 |
| Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
| Anzahl Gigabit Ethernet (Kupfer) Anschlüsse | 4 |
| Anzahl 2.5G Ethernet (Kupfer)-Ports | 4 |
| Konsolen-Port | RJ-45 |
| Anzahl SFP28-Ports | 2 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.1D. IEEE 802.1s. IEEE 802.1w. IEEE 802.3af. IEEE 802.3at. IEEE 802.3bt |
| unterstütze Kabeltypen | Cat6. Cat7 |
| Virtuelle LAN-Funktionen | Voice VLAN |
| Anzahl der VLANs | 4093 |
| Durchsatz | 188 Gbit/s |
| MAC-Adressentabelle | 16000 Eintragungen |
| Jumbo-Frames | 10240 |
| DHCP-Funktionen | DHCP server |
| IGMP-Einträge | 1024 |
| Autentifizierungstyp | IEEE 802.1x. RADIUS. TACACS+ |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| Gehäusematerial | Metall |
| Anzahl Lüfter | 2 Lüfter |
| Energiequelle | AC |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 35 W |
| Anzahl Power over Ethernet (PoE) Anschlüsse | 4 |
| Gesamtleistung Power over Ethernet (PoE) | 370 W |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Breite | 442 mm |
| Tiefe | 44 mm |
| Höhe | 211 mm |
| Gewicht | 2.35 kg |
| Verpackungsbreite | 570 mm |
| Verpackungstiefe | 400 mm |
| Verpackungshöhe | 100 mm |
| Paketgewicht | 3.75 kg |
| Zolltarifnummer (TARIC) | 85176200 |
| Ursprungsland | Taiwan |
