Intel Core i7-9700 - 9th Gen LGA1151, 8 Cores 3.0 GHz (4.7 GHz Turbo), 65W, Intel UHD 630
Intel Core i7-9700 (tray) 9th Gen, LGA1151, 8 cores/8 threads, 3.0 GHz base up to 4.7 GHz Turbo, 12 MB cache, Intel UHD 630, DDR4 support, 65W TDP.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Series / Family | Intel Core i7 |
|---|---|
| CPU (Processors) - Cores | 8 |
| CPU (Processors) - Threads | 8 |
| CPU (Processors) - TDP | 65 W |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Core i7-9700. Processor family: Intel® Core™ i7. Processor socket: LGA 1151 (Socket H4). Processor lithography: 14 nm. Memory channels: Dual-channel. Maximum internal memory supported by processor: 128 GB. Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel® UHD Graphics 630. Maximum on-board graphics card memory: 64 GB. On-board graphics card base frequency: 350 MHz. Market segment: Desktop. PCI Express configurations: 1x16. 2x8. 1x8+2x4. Supported instruction sets: SSE4.1. SSE4.2. AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 4.7 GHz
| Processor manufacturer | Intel |
| Processor generation | 9th gen Intel® Core™ i7 |
| Processor model | i7-9700 |
| Processor base frequency | 3 GHz |
| Processor family | Intel® Core™ i7 |
| Processor cores | 8 |
| Processor socket | LGA 1151 (Socket H4) |
| Component for | PC |
| Processor lithography | 14 nm |
| Processor threads | 8 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.7 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 65 W |
| Package type | Box. Tray |
| Generation | 9th Generation |
| Memory bandwidth supported by processor (max) | 41.6 GB/s |
| Processor codename | Coffee Lake |
| Processor ARK ID | 191792 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Dual-channel |
| Feature | Intel® vPro™ Platform Eligibility |
| On-board graphics card model | Intel® UHD Graphics 630 |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics card ID | 0x3E98 |
| Discrete graphics card model | Not available |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16. 2x8. 1x8+2x4 |
| Supported instruction sets | SSE4.1. SSE4.2. AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015C |
| PCI Express CEM revision | 3.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 4.7 GHz |
| Tjunction | 100 °C |
| Launch date | Q2'19 |
| Maximum resolution & refresh rate (DisplayPort) | 4096 x 2304@60Hz |
| Product type | Processor |
| Status | Launched |
| Maximum memory | 128 GB |
| Supported memory types | DDR4-SDRAM |
| Bus speed | 8 GT/s |
| Maximum graphics card memory | 64 GB |
| Processor ID | 0x3E98 |
| Harmonized System (HS) code | 8542310001 |
| Processor package size | 37.5 x 37.5 mm |
| Maximum internal memory | 128 GB |
