Intel Xeon Gold 5218 - LGA3647 Tray, 16C/32T, 2.3GHz base (3.9GHz boost), 125W, DDR4, Cascade Lake
Intel Xeon Gold 5218 server CPU — 16 cores / 32 threads, 2.3 GHz base, 3.9 GHz turbo, 22 MB cache, 125W TDP, LGA3647, hexa-channel DDR4, up to 1.02 TB memory.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Cores | 16 |
|---|---|
| CPU (Processors) - Threads | 32 |
| CPU (Processors) - TDP | 120-125 W |
| CPU (Processors) - Integrated Graphics | None |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - PCIe Version | PCIe 3.0 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Xeon 5218. Processor family: Intel® Xeon® Gold. Processor socket: LGA 3647 (Socket P). Processor lithography: 14 nm. Memory channels: Hexa-channel. Maximum internal memory supported by processor: 1.02 TB. Memory types supported by processor: DDR4-SDRAM. Market segment: Server. Supported instruction sets: SSE4.2. AVX. AVX 2.0. AVX-512. Scalability: 4S. Package width: 43 mm. Package depth: 137 mm. Package height: 112 mm. Processor package size: 76mm x 56.5mm
| Processor manufacturer | Intel |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 5218 |
| Processor base frequency | 2.3 GHz |
| Processor family | Intel® Xeon® Gold |
| Processor cores | 16 |
| Processor socket | LGA 3647 (Socket P) |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.9 GHz |
| Processor cache | 22 MB |
| Thermal Design Power (TDP) | 125 W |
| Package type | Box. Tray |
| Processor codename | Cascade Lake |
| Processor ARK ID | 192444 |
| Maximum internal memory supported by processor | 1.02 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2667 MHz |
| Memory channels | Hexa-channel |
| Feature | Intel® Optane™ DC Persistent Memory technology |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2. AVX. AVX 2.0. AVX-512 |
| Scalability | 4S |
| PCI Express CEM revision | 3.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Intel® Turbo Boost Technology | 2.0 |
| AVX-512 Fused Multiply-Add (FMA) units | 1 |
| Tcase | 87 °C |
| Launch date | Q2'19 |
| Product type | Processor |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Memory speed (max) | 2667 MHz |
| Number of UPI links | 2 |
| Servicing status | Baseline Servicing |
| Harmonized System (HS) code | 85423119 |
| Package width | 43 mm |
| Package depth | 137 mm |
| Package height | 112 mm |
| Package weight | 201 g |
| Processor package size | 76mm x 56.5mm |
| Maximum internal memory | 1 TB |
