Intel Core i5-13500 13th Gen Raptor Lake LGA1700 14C/20T up to 4.8GHz UHD 770 (Tray)
Intel Core i5-13500 (13th Gen Raptor Lake) LGA1700 tray CPU: 14 cores (6P+8E), 20 threads, up to 4.8GHz boost, UHD Graphics 770, DDR4/DDR5, PCIe 5.0 support, 65W TDP.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i5 |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Threads | 20 |
| CPU (Processors) - TDP | 46-65W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Core i5-13500 is a 13th Gen Raptor Lake desktop processor featuring a hybrid architecture with 6 Performance-cores (P-cores) at 2.5GHz base / 4.8GHz boost and 8 Efficient-cores (E-cores) at 1.8GHz base / 3.5GHz boost, delivering 14 cores and 20 threads total. Built on Intel 7 process, it offers 24MB L3 Smart Cache, supports DDR4/DDR5 dual-channel memory up to 192GB, and PCIe 5.0 with 20 lanes. Ideal for gaming, productivity, and multitasking with 65W base power (154W max turbo).
This tray version (OEM, no retail box/cooler) targets system builders. Benchmarks show it outperforms Ryzen 5 7600 in multi-threaded tasks like Blender (28% faster) and matches i5-13600K closely in gaming (e.g., 228 FPS DDR5 in Tomb Raider). Integrated Intel UHD Graphics 770 supports 4 displays up to 8K@60Hz. Launched Q1 2023, ARK ID 230580.
- Socket: LGA1700 (600/700 series chipsets)
- Memory: DDR5-4800 / DDR4-3200, 76.8GB/s bandwidth
- Graphics Outputs: HDMI 2.1, DP 1.4a, eDP 1.4b
- Tech: Turbo Boost 2.0, AVX2, no overclocking
- TDP: 65W base, 154W turbo, Tjunction 100°C
| Processor manufacturer | Intel |
| Processor generation | 13th gen Intel® Core™ i5 |
| Processor model | i5-13500 |
| Processor family | Intel® Core™ i5 |
| Processor cores | 14 |
| Processor socket | LGA 1700 |
| Processor threads | 20 |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 4.8 GHz |
| Performance-core boost frequency | 4.8 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core boost frequency | 3.5 GHz |
| Efficient-core base frequency | 1.8 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 65 W |
| Maximum turbo power | 154 W |
| Bus type | DMI4 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 230580 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory channels | Dual-channel |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1550 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| PCI Express slots version | 5.0, 4.0 |
| Maximum number of PCI Express lanes | 20 |
| Tjunction | 100 °C |
| Launch date | Q1'23 |
| Processor package size | 45 x 37.5 mm |
