Intel Xeon Gold 6342 - 24C/48T 2.8GHz (3.5GHz Turbo), 36MB Cache, 230W, LGA4189, DDR4 (Tray)
Intel Xeon Gold 6342 server CPU — 24 cores / 48 threads, 2.8 GHz base, 3.5 GHz boost, 36 MB cache, 230W TDP, LGA4189, DDR4, tray package.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Cores | 24 |
|---|---|
| CPU (Processors) - Threads | 48 |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - PCIe Version | PCIe 4.0 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Xeon Gold 6342. Processor family: Intel® Xeon®. Processor socket: LGA 4189. Processor lithography: 10 nm. Memory channels: Octa-channel. Memory types supported by processor: DDR4-SDRAM. Market segment: Server. Supported instruction sets: SSE4.2. AVX. AVX 2.0. AVX-512. Scalability: 2S. Maximum Enclave Size Support for Intel® SGX: 64 GB. Processor package size: 77.5 x 56.5 mm
| Processor manufacturer | Intel |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor model | 6342 |
| Processor base frequency | 2.8 GHz |
| Processor family | Intel® Xeon® |
| Processor cores | 24 |
| Processor socket | LGA 4189 |
| Component for | Server/workstation |
| Processor lithography | 10 nm |
| Processor threads | 48 |
| System bus rate | 11.2 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.5 GHz |
| High priority cores | 12 |
| High priority core frequency | 2.9 GHz |
| Low priority cores | 12 |
| Low priority core frequency | 2.6 GHz |
| Processor cache | 36 MB |
| Thermal Design Power (TDP) | 230 W |
| Package type | Tray. - |
| Processor codename | Ice Lake |
| Processor ARK ID | 215276 |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Octa-channel |
| Feature | Intel® Optane™ DC Persistent Memory Supported |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Server |
| Maximum number of PCI Express lanes | 64 |
| PCI Express slots version | 4.0 |
| Supported instruction sets | SSE4.2. AVX. AVX 2.0. AVX-512 |
| Scalability | 2S |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G178966 |
| Intel® Turbo Boost Technology | 2.0 |
| Maximum Enclave Size Support for Intel® SGX | 64 GB |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Tcase | 81 °C |
| Target market | Cloud Computing |
| Launch date | Q2'21 |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Memory speed (max) | 3200 MHz |
| Number of UPI links | 3 |
| Servicing status | Baseline Servicing |
| Harmonized System (HS) code | 85423119 |
| Processor package size | 77.5 x 56.5 mm |
| Maximum internal memory | 6 TB |
