Intel Core i3-14100 - LGA1700 Tray - 4C/8T, 4.7GHz Boost, Intel UHD 730, DDR4/DDR5, PCIe 5.0
Intel Core i3-14100 (14th Gen) LGA1700 tray CPU — 4 cores / 8 threads, up to 4.7 GHz, Intel UHD 730 graphics, DDR4 & DDR5 support, PCIe 5.0/4.0.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Series / Family | Intel Core i3 |
|---|---|
| CPU (Processors) - Socket | LGA1700 |
| CPU (Processors) - Cores | 4 |
| CPU (Processors) - Threads | 8 |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Core i3-14100. Processor family: Intel® Core™ i3. Processor socket: LGA 1700. Package type: Tray. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 730. On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1. On-board graphics card dynamic frequency (max): 1500 MHz. Market segment: Desktop. Use conditions: PC/Client/Tablet. PCI Express slots version: 4.0. 5.0. Processor package size: 45 x 37.5 mm
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i3 (14th gen) |
| Processor model | i3-14100 |
| Processor family | Intel® Core™ i3 |
| Processor cores | 4 |
| Processor socket | LGA 1700 |
| Processor threads | 8 |
| Processor operating modes | 64-bit |
| Performance cores | 4 |
| Processor boost frequency | 4.7 GHz |
| Performance-core boost frequency | 4.7 GHz |
| Performance-core base frequency | 3.5 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 60 W |
| Maximum turbo power | 110 W |
| Stepping | H0 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236774 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 76.8 GB/s |
| Feature | Intel® Standard Manageability (ISM) |
| On-board graphics card model | Intel UHD Graphics 730 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1 |
| On-board graphics card dynamic frequency (max) | 1500 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card ID | 0x4692 |
| Discrete graphics card model | Not available |
| Number of execution units | 24 |
| Multi-Format Codec Engines | 1 |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0. 5.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Tjunction | 100 °C |
| OpenCL version | 3.0 |
| Launch date | Q1'24 |
| Status | Launched |
| Harmonized System (HS) code | 8542310001 |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 5120 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b. DP 1.4a. HDMI 2.1 |
