CS-8132F-F2B
LANCOM CS-8132F-F2B. Managed. L2/L3. Vollduplex. Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LANCOM CS-8132F-F2B. Switch-Typ: Managed. Switch-Ebene: L2/L3. Konsolen-Port: RJ-45. Vollduplex. MAC-Adressentabelle: 32000 Eintragungen. Netzstandard: IEEE 802.1AX. IEEE 802.1D. IEEE 802.1Q. IEEE 802.1w. Netzstecker: AC-Eingangsbuchse. Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3 |
| Feature | Betriebsanleitung |
| MIB Unterstützung | MIB II. Bridge MIB. Interface MIB. SMON MIB. IGMP MIB. IEEE 802.3 MAU MIB |
| Konsolen-Port | RJ-45 |
| Anzahl QSFP28-Ports | 32 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.1AX. IEEE 802.1D. IEEE 802.1Q. IEEE 802.1w |
| IPv4-Routen | 16000 |
| IPv6-Routen | 16000 |
| Virtuelle LAN-Funktionen | Private VLAN. Voice VLAN |
| Anzahl der VLANs | 4093 |
| Durchsatz | 32000 Gbit/s |
| MAC-Adressentabelle | 32000 Eintragungen |
| Jumbo-Frames | 12288 |
| Datenpaket-Pufferspeicher | 32 MB |
| DHCP-Funktionen | DHCP client. DHCP relay. DHCP server |
| Unterstützte Sicherheitsalgorithmen | SNMP. SNMPv2. SNMPv3 |
| Autentifizierungstyp | IEEE 802.1x. RADIUS. TACACS+ |
| Management-Protokolle | SNMP |
| Router Protokoll | BGP4. OSPFv2. OSPFv3 |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| Anzahl Lüfter | 3 Lüfter |
| Prozessortaktfrequenz | 1600 MHz |
| Speichertyp | DDR4-SDRAM |
| Speicherkapazität | 8192 MB |
| Geräuschpegel | 65 dB |
| Energiequelle | AC |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 310 W |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Wärmeableitung | 1060 BTU/h |
| Breite | 446 mm |
| Tiefe | 480 mm |
| Höhe | 43.8 mm |
| Gewicht | 7.44 kg |
| Verpackungsbreite | 540 mm |
| Verpackungstiefe | 660 mm |
| Verpackungshöhe | 180 mm |
| Paketgewicht | 7.45 kg |
| Zolltarifnummer (TARIC) | 85176200 |
| Ursprungsland | Taiwan |
