Intel Core Ultra 9 285K - 24-Core 24-Thread Desktop CPU DDR5 LGA1851 (Tray)
Intel Core Ultra 9 285K: 24-core (8P+16E) desktop processor with DDR5 support, integrated Intel Graphics, AI Boost NPU (13 TOPS), LGA1851 socket, up to 5.7 GHz boost, 125W base TDP.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1851 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core Ultra 9 |
| CPU (Processors) - Cores | 24 |
| CPU (Processors) - Threads | 24 |
| CPU (Processors) - TDP | 96-120W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core Ultra 9 285K is a high-performance desktop processor featuring 24 cores (8 Performance cores + 16 Efficient cores) and 24 threads, built on Intel's Arrow Lake architecture. With a base frequency of 3.7 GHz and boost up to 5.7 GHz, this processor delivers strong multi-threaded performance, achieving Cinebench 2024 scores of 2,500+ points—approximately 14% faster than the Core i9-14900K and 7% faster than AMD Ryzen 9 9950X in productivity workloads. The processor supports DDR5-6400 memory up to 192GB capacity and features 36MB of Smart Cache (L2+L3).
The 285K integrates Intel Graphics with 4 Xe-cores and includes Intel AI Boost NPU capable of 13 TOPS, contributing to a total system performance of 36 TOPS when combined with CPU and GPU capabilities. It supports 20 PCIe 5.0 lanes, enabling 16x for discrete GPUs and 4x for NVMe storage. The processor operates at a base TDP of 125W with maximum turbo power of 250W, representing improved power efficiency compared to previous-generation Intel CPUs. However, gaming performance shows a 5% deficit versus the 14900K and 28% deficit versus AMD's 7800X3D, making it better suited for productivity and content creation workloads.
Key Features:
- 24 cores / 24 threads (8 Performance + 16 Efficient cores)
- Base: 3.7 GHz | Boost: 5.7 GHz (Thermal Velocity Boost)
- LGA1851 socket with DDR5-6400 memory support (up to 192GB)
- Integrated Intel Graphics (4 Xe-cores, up to 2.0 GHz)
- Intel AI Boost NPU: 13 TOPS performance
- 36MB Smart Cache (L3) + 40MB L2 cache
- 20x PCIe 5.0 lanes (16x GPU + 4x NVMe)
- Base TDP: 125W | Max Turbo: 250W
- Supports DirectML, OpenVINO, Windows ML, ONNX RT, WebNN frameworks
- Tray packaging (processor only, cooler not included)
| Processor Manufacturer | Intel |
| Processor Generation | Intel Core Ultra (Series 2) |
| Processor Model | 285K |
| Processor Family | Intel Core Ultra 9 |
| Processor Cores | 24 (8 Performance + 16 Efficient) |
| Processor Threads | 24 |
| Processor Socket | LGA 1851 (Socket V1) |
| Performance-Core Base Frequency | 3.7 GHz |
| Performance-Core Boost Frequency | 5.6 GHz |
| Efficient-Core Base Frequency | 3.2 GHz |
| Efficient-Core Boost Frequency | 4.6 GHz |
| Thermal Velocity Boost Frequency | 5.7 GHz |
| Turbo Boost Max Technology 3.0 | 5.6 GHz |
| Processor Cache (L2+L3) | 76 MB (40 MB L2 + 36 MB L3) |
| L2 Cache | 40 MB (8 cores × 3 MB per P-core + 8 cores × 2 MB per E-core) |
| L3 Cache | 36 MB (Shared Smart Cache) |
| Base TDP | 125 W |
| Maximum Turbo Power | 250 W |
| Package Type | Tray |
| Processor Architecture | Arrow Lake |
| Processor Codename | Arrow Lake |
| Stepping | B0 |
| Memory Support | DDR5-SDRAM |
| Memory Speed | 6400 MT/s |
| Memory Channels | Dual-channel |
| Maximum Memory Capacity | 192 GB |
| Integrated Graphics | Intel Graphics (4 Xe-cores) |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Frequency | 2000 MHz |
| Graphics Outputs Supported | HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1 |
| Max Resolution (DisplayPort) | 7680 × 4320 @ 60 Hz |
| Max Resolution (eDP) | 3840 × 2400 @ 120 Hz |
| Number of Displays Supported | 4 |
| Graphics DirectX Support | 12.0 |
| Graphics OpenGL Support | 4.5 |
| Neural Processing Unit (NPU) | Intel AI Boost |
| NPU Performance | 13 TOPS |
| Total System Performance | 36 TOPS (CPU + GPU + NPU combined) |
| AI Software Frameworks | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| PCI Express Lanes | 24 (20 Gen 5.0 + 4 Gen 4.0) |
| PCI Express Versions | Gen 4.0, Gen 5.0 |
| Direct Media Interface (DMI) | DMI 4.0 (8 lanes) |
| Instruction Sets | AVX 2.0, SSE4.1, SSE4.2 |
| Turbo Boost Technology | Intel Turbo Boost 2.0 |
| Thermal Solution Specification | PCG 2020A |
| Maximum Operating Temperature | 105 °C |
| Operating Modes | 64-bit |
| Scalability | 1S (Single Socket) |
| Market Segment | Desktop |
| Use Cases | Workstation, PC/Client/Tablet, Content Creation, Productivity |
| Launch Date | Q4 2024 |
| Status | Launched |
| Intel ARK ID | 241060 |
| Security Features | Intel Total Memory Encryption - Multi Key |
| Cinebench 2024 Multi-Core Performance | 2,500+ points (14% faster than Core i9-14900K, 7% faster than Ryzen 9 9950X) |
| 7-Zip Compression Efficiency | 1051 MIPS/W (56% improvement over Core i9-14900K) |
| Gaming Performance (14-Game Average) | 5% slower than Core i9-14900K, 28% slower than Ryzen 7 7800X3D |
| Cooler Included | No (Tray format - processor only) |
