Intel Core i5-12400 LGA1700 Tray 6-Core 2.5-4.4GHz 65W UHD 730
Intel Core i5-12400 (Tray, LGA1700): 6 P-cores/12 threads, 2.5GHz base to 4.4GHz turbo, 65W TDP (117W max), 18MB cache. UHD Graphics 730, DDR4/DDR5 support, PCIe 5.0. Excellent gaming value CPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i5 |
| CPU (Processors) - Cores | 6 |
| CPU (Processors) - Threads | 12 |
| CPU (Processors) - TDP | 46-65W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Core i5-12400 is a 12th Gen Alder Lake desktop processor featuring 6 performance cores (P-cores) and 12 threads with Hyper-Threading. It delivers base clock of 2.5 GHz boosting up to 4.4 GHz, with 18 MB Intel Smart Cache and 65W TDP (max turbo power 117W). Built on Intel 7 process, it supports LGA 1700 socket, dual-channel DDR4-3200 or DDR5-4800 memory up to 128 GB, and PCIe 5.0 for modern platforms.
This Tray version lacks a retail box or cooler, ideal for OEM/bulk builders. Integrated Intel UHD Graphics 730 (24 EUs, up to 1.45 GHz) supports 4 displays with HDMI 2.1, DP 1.4a, eDP 1.4b. Non-overclockable (locked multiplier), it's optimized for gaming and productivity, outperforming Ryzen 5 5600X in many benchmarks while staying power-efficient.
- 6 P-cores / 12 threads (no E-cores)
- PCIe 5.0 (20 lanes): 1x16+1x4 or 2x8+1x4 configs
- Integrated GPU: DirectX 12, OpenGL 4.5, 4K support
- Launch: Q1 2022, codename Alder Lake
- Compatible with 600/700 series chipsets
| Processor manufacturer | Intel |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor model | i5-12400 |
| Processor family | Intel® Core™ i5 |
| Processor cores | 6 |
| Processor socket | LGA 1700 |
| Processor threads | 12 |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Processor boost frequency | 4.4 GHz |
| Performance-core boost frequency | 4.4 GHz |
| Performance-core base frequency | 2.5 GHz |
| Processor cache | 18 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 65 W |
| Maximum turbo power | 117 W |
| Bus type | DMI4 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Processor codename | Alder Lake |
| Processor ARK ID | 134586 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-3200, DDR5-4800 |
| Memory channels | Dual-channel |
| On-board graphics card model | Intel UHD Graphics 730 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1450 MHz |
| Number of displays supported (on-board graphics) | 4 |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 5.0, 4.0 |
| Tjunction | 100 °C |
| Launch date | Q1'22 |
| Processor package size | 45 x 37.5 mm |
| L2 Cache | 7.5 MB (6 x 1280 KB) |
| L3 Cache | 18 MB |
