Intel Xeon E-2356G 6-Core 3.2GHz (5.0GHz Turbo) LGA1200 80W UHD P750 (Tray)
Intel Xeon E-2356G tray CPU: 6 cores/12 threads, 3.2GHz base (5.0GHz turbo), 12MB cache, 80W TDP, LGA1200 socket. Supports DDR4-3200 up to 128GB dual-channel ECC, Intel UHD P750 graphics. Ideal for workstations/servers.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1200 |
|---|---|
| CPU (Processors) - Processor Family | Intel Xeon E |
| CPU (Processors) - Cores | 6 |
| CPU (Processors) - Threads | 12 |
| CPU (Processors) - TDP | 66-95W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
The Intel Xeon E-2356G is a high-performance 6-core, 12-thread processor from the Rocket Lake-E family, designed for entry-level servers and workstations. Featuring a 3.2 GHz base frequency with Intel Turbo Boost 2.0 up to 5.0 GHz, 12MB Smart Cache, and 80W TDP, it delivers efficient multi-threaded performance for demanding workloads like virtualization and data processing.
This LGA1200 (FCLGA1200) tray processor includes integrated Intel UHD Graphics P750 with 32 execution units, supporting up to 64GB shared memory, 4K@60Hz output, and Quick Sync Video for hardware acceleration. It supports dual-channel DDR4-3200 memory up to 128GB (ECC capable), PCIe 4.0 with 20 lanes, and advanced features like AVX-512, vPro, and SGX for enhanced security and manageability.
- ✅ 6 Cores / 12 Threads with Hyper-Threading
- ✅ 3.2 GHz Base / 5.0 GHz Max Turbo
- ✅ Integrated UHD P750 Graphics (350MHz-1.3GHz)
- ✅ DDR4-3200 Dual-Channel up to 128GB ECC
- ✅ 80W TDP, No Cooler Included (Tray)
- ✅ PCIe 4.0 (20 Lanes), LGA1200 Socket
| Processor manufacturer | Intel |
| Processor model | E-2356G |
| Processor family | Intel Xeon E |
| Processor base frequency | 3.2 GHz |
| Processor cores | 6 |
| Processor socket | LGA 1200 |
| Processor threads | 12 |
| Processor boost frequency | 5.0 GHz |
| Processor cache | 12 MB Intel Smart Cache |
| Thermal Design Power (TDP) | 80 W |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-3200 |
| Memory channels | 2 |
| On-board graphics card model | Intel UHD Graphics P750 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1.30 GHz |
| Market segment | Server/Workstation |
| PCI Express slots version | 4.0 |
| Maximum number of PCI Express lanes | 20 |
| Tjunction | 100 °C |
| Package type | Tray |
| Launch date | Q3'21 |
| Architecture | Rocket Lake-E |
| Step Code | SRKN2 |
| ECC memory support | Yes |
